FTTH-XY-B-24 24 Core Fiber Optic distribution box Fiber to The Home Box
FTTH-XY-B-24 24 Core Fiber Optic distribution box Fiber to The Home Box
FTTH-XY-B-24 24 Core Fiber Optic distribution box Fiber to The Home Box
FTTH-XY-B-24 24 Core Fiber Optic distribution box Fiber to The Home Box
FTTH-XY-B-24 24 Core Fiber Optic distribution box Fiber to The Home Box
FTTH-XY-B-24 24 Core Fiber Optic distribution box Fiber to The Home Box
FTTH-XY-B-24 24 Core Fiber Optic distribution box Fiber to The Home Box
FTTH-XY-B-24 24 Core Fiber Optic distribution box Fiber to The Home Box
Specifications
Brand Name :
XYFiber/ OEM
Model Number :
FTTH-XY-B-24
Certification :
SGS, RoHS
Place of Origin :
Shanghai,China
MOQ :
1 PC
Payment Terms :
T/T, Western Union, MoneyGram, L/C, Monthly
Supply Ability :
1000PCS/Day
Delivery Time :
3-5 days
Packaging Details :
1PC/ Carton
Description

FTTH-XY-B-24D

24core fiber optic distribution box complies with YD/T2150-2010. Using PC injecting method. It comes with good sealing and anti-aging abilities. Can be used in outdoor/outdoor wall mounting, etc.

Technical Specs:

  1. Environmental:

Operating Temperature: -40℃～+60℃

Humidity: ≤95%(+40℃)

Atmosphere Pressure: 70KPa～108 KPa

  1. Structure and Dimensions

325(H)×275(W)×100(D)mm

FTTH-XY-B-24D is made up of Body, splitter holer, splice tray, cable fixed grounding units, zip fixing unit, sealing assemblies, cable ring components etc.

FTTH-XY-B-24D 24core fiber optic distribution box complies with YD/T2150-2010. Using PC injecting method. It comes with good sealing and anti-aging abilities. Can be used in outdoor/outdoor wall mounting, etc.

Technical Specs:

  1. Environmental:

Operating Temperature: -40℃～+60℃

Humidity: ≤95%(+40℃)

Atmosphere Pressure: 70KPa～108 KPa

  1. Structure and Dimensions

325(H)×275(W)×100(D)mm

FTTH-XY-B-24D is made up of Body, splitter holer, splice tray, cable fixed grounding units, zip fixing unit, sealing assemblies, cable ring components etc.

​

Packing List:

Part Name Descr. Q’ty Remarks
Box Body XY-B-24D 1
Heat shrinkable tube Ф1.5×40mm 24
insulated rubber tape 14mm×5m×0.15mm 1 roll
Protection tube Φ5 1.5m
Nylon cable ties 3×100mm 24
Screws M8×40mm 4sets
Key 1
QC PASS Label 1
Specs 1
