Specifications
Brand Name :
YGHT
Model Number :
MG93AR-800-20X
Certification :
CE,FCC
Place of Origin :
Shenzhen, China
MOQ :
1 PCS
Price :
Price on Application
Payment Terms :
T/T
Supply Ability :
100K PCS/Month
Delivery Time :
2-31 DAYS
Packaging Details :
23*17*29CM 1.9KG / 1unit , 49*37*60CM 16KG / 8units
Sensor :
1/3 inch CMOS
Video Compression :
H.265+
Effective Pixels :
8.0 Megapixels
Lens :
20X optical zoom f=4.7-84.6mm
Minimum Illumination :
Full Color Night Vision
IR Distance :
Up to 100 meters
TF Card Support :
Up to 512G
Audio Compression Standard :
G711, PCM
Audio :
Built-in Mic & Speaker
Compatibility :
Seetong App
Pan/Tilt Range :
360° pan, 90° tilt (auto flip)
Operating Temperature :
-40°C to +60°C (outdoor), 0°C to +40°C (indoor)
Humanoid Detection :
Supported
Vehicle Detection :
Supported
Description

High-Resolution Imaging and Superior Night Vision

The 8.0MP PTZ Camera delivers exceptional image quality, perfect for all your surveillance needs. With a 1/3 inch CMOS sensor and a resolution of 8.0 megapixels, this camera captures high-definition footage, ensuring you don't miss any details. The 20X optical zoom lens (4.7-84.6mm) allows for close-up views of distant objects without compromising clarity. Whether you're monitoring large areas or focusing on specific points of interest, this camera provides flexibility and precision.

Equipped with full-color night vision and IR-CUT technology, the camera excels in low-light conditions. The IR LEDs provide illumination up to 100 meters, ensuring clear visibility even in complete darkness. This makes it ideal for round-the-clock surveillance of outdoor and indoor spaces, including parking lots, warehouses, and large properties.

Advanced Detection and Two-Way Audio

This PTZ camera is packed with advanced features to enhance your security system. It supports vehicle detection and humanoid tracking, ensuring that all movements within the camera's range are captured and analyzed. This feature is particularly useful for monitoring entrances, driveways, and perimeters, providing you with comprehensive security coverage.

The built-in microphone and speaker support two-way audio, allowing for real-time communication with anyone in the camera's vicinity. This feature is invaluable for interactive security setups, enabling you to issue warnings, provide instructions, or engage with visitors directly through the camera. Whether you're managing a residential security system or overseeing a commercial property, the two-way audio functionality adds an extra layer of control and responsiveness.

Reliable Performance and Easy Integration

Designed for durability and reliability, the 8.0MP PTZ Camera is suitable for both indoor and outdoor use. With an operating temperature range of -40°C to +60°C for outdoor environments and 0°C to +40°C for indoor settings, this camera performs well under various weather conditions. Its IP66 rating ensures that it is dust-tight and water-resistant, providing long-lasting performance in harsh environments.

Power over Ethernet (POE) support simplifies the installation process by combining power and data transmission over a single cable. This reduces the need for additional wiring, making the setup more efficient and cost-effective. The camera also supports TF cards up to 512G, offering ample local storage for recorded footage.

Compatible with the Seetong app, the camera allows for remote access and control from your smartphone. You can monitor live feeds, adjust settings, and review recorded footage from anywhere, providing you with flexibility and convenience. The camera supports a wide range of communication protocols, including TCP/IP, HTTP, NTP, IGMP, DHCP, UDP, SMTP, RTP, RTSP, ARP, DDNS, DNS, HTTPS, and P2P, ensuring seamless integration with your existing network systems.

Robust Security Features

The camera's pan and tilt capabilities include a 360° continuous rotation and a tilt range of 0° to 90° with auto flip, providing comprehensive coverage of large areas. The horizontal speed ranges from 0.1° to 45° per second, while the vertical speed ranges from 0.1° to 45° per second, allowing for smooth and precise movement. With up to 128 preset points, 1 pattern scan group, 8 guard tour groups, and 16 guard points with user-selectable dwell times, the camera offers extensive customization options to meet your specific surveillance needs.

ODM 8.0MP Network PTZ Camera 20X 4k Pan Tilt Zoom Full Color Night VisionODM 8.0MP Network PTZ Camera 20X 4k Pan Tilt Zoom Full Color Night Vision

Imaging and Optical Specifications

Specification Details
Sensor 1/2.8" NOVA+SONY415
Effective Pixels 3840x2160
Total Pixels 8.0 Megapixels
Output Pixel 3840x2160@18fps, 2592x1944@22fps, 2592x1520@25fps, 1920x1080@30fps
Lens 20X optical zoom f=4.7-84.6mm
Auto Iris F1.4-4.3 auto iris
Field of View (FOV) 3.8° - 72°
Minimum Illumination Color: 0.05 Lux / B/W: 0 Lux
Day/Night Mode IR-CUT
Backlight Compensation (BLC) Auto
White Balance (WB) Auto
Signal-to-Noise Ratio (S/N) ≥80dB (AGC OFF)
IR Distance Infrared: 60 meters / Full Color: 40 meters
LED Φ42 9pcs infrared / Φ42 6pcs Full Color

Network and Additional Specifications

Specification Details
Video Compression H.265+ Main Profile/H.265 Main Profile / H.264 High Profile
TF Card Support 512G
Audio Frequency Optional
Audio Compression Standard G711, PCM
Communications Protocol TCP/IP, HTTP, NTP, IGMP, DHCP, UDP, SMTP, RTP, RTSP, ARP, DDNS, DNS, HTTPS, P2P
Compatibility IE, SEETONG, ONVIF
Mobile View (Optional) Support Windows, Symbian, iPhone platform smartphone
P2P Android, iOS
Preset Points 128
Pattern Scan 1 group
Guard Tours 8 groups
Guard Points Max. 16 points, dwell time user selectable
Tilt Range 0~90° (Auto Flip)
Pan Range 360° continued rotation
Horizontal Speed Level keying speed: 0.1° ~ 45° / s
Vertical Speed Vertical keying speed: 0.1° ~ 45° / s
Pan and Tilt Position Display Support
Auto Control IR LED PWM
Support Ambient Light Detection IR illumination on 1-15 grades selectable
Humidity ≤95% Non-Condensing
Power DC12V ≤3A or POE
Consumption < 20W
Operating Temperature Indoor: 0°~ +40°, Outdoor: -40°~ +60°
Lightning Protection Transient voltage 6000V
Interface 1 channel network interface, power input
Size/Weight 2.5KG
Related Validation IP66, CE, FCC, RoHS

This 8.0MP PTZ Camera is the perfect solution for those seeking high-quality, reliable surveillance. Its advanced features, robust performance, and user-friendly design make it an ideal choice for a wide range of applications, from residential security to commercial monitoring. With this camera, you can ensure that every corner of your property is protected, day and night.
