Specifications
Brand Name :
YGHT
Model Number :
MG07AR-800-5X
Certification :
CE,FCC
Place of Origin :
Shenzhen, China
MOQ :
1 PCS
Price :
Price on Application
Payment Terms :
T/T
Supply Ability :
100K PCS/Month
Delivery Time :
2-31 DAYS
Packaging Details :
22*20*14CM 1.4KG 1 / unit , 43*43*46CM 17.5KG 12 / units
Image Sensor :
1/2.8" CMOS
Effective Pixels :
8.0 Megapixels
Optical Zoom :
5X (2.8-12mm)
IR Distance :
Up to 60 meters
Housing Material :
Metal
Video Compression :
H.265+
Electronic Shutter :
1/25s~1/50,000s, 1/30s~1/60,000s
Minimum Illumination :
0.01Lux@F1.2 (AGC ON), 0Lux IR on
Audio Support :
Two-way audio
Network Interface :
Built-in RJ45, supports 10M/100M IP data
Power Supply :
DC12V±10% or POE
Ingress Protection :
IP67
Application :
Supports Web4.0, TF card up to 512GB, APP: Seetong
Special Features :
Vehicle detection, humanoid tracking and detection
Description

Superior Imaging and Zoom Capabilities

The 5X Optical Zoom PTZ Camera is engineered to provide high-definition surveillance with its advanced 1/2.8" CMOS sensor and NOVA+SONY415 technology, delivering crisp and clear 8.0-megapixel images. The 5X optical zoom lens (2.8-12mm) allows for detailed viewing and flexible monitoring, ensuring you capture every crucial moment. With an IR-CUT filter and Nano-tech IR LEDs, this camera offers impressive night vision capabilities, providing clear images up to 60 meters in complete darkness.

Intelligent Detection and Tracking

Equipped with advanced humanoid tracking and detection, this PTZ camera is designed to follow human movements within its field of view, significantly enhancing security by ensuring that no important event goes unnoticed. Additionally, the camera supports vehicle detection, making it ideal for monitoring parking areas, driveways, and other locations where vehicle movement needs to be tracked. These intelligent features reduce false alarms and provide accurate monitoring, ensuring reliable surveillance.

Robust Build and Comprehensive Compatibility

The camera is housed in a durable metal casing, offering superior protection against harsh environmental conditions. With an IP67 rating, it is resistant to dust and water, making it suitable for both indoor and outdoor installations. The camera supports a wide range of network protocols, including TCP/IP, HTTP, DHCP, DDNS, RTP, RTSP, PPPOE, SMTP, NTP, and UPNP, ensuring seamless integration with existing security systems. It is compatible with the Seetong app for remote access via Android and iOS devices, and supports ONVIF, Hikvision, XM, and Jovision personal protocols for enhanced interoperability.

Flexible Storage and Easy Installation

Supporting TF cards up to 512GB, this camera offers ample storage for extensive recording. The H.265+ video compression standard ensures efficient storage utilization without compromising video quality. Power over Ethernet (POE) support simplifies installation by allowing both power and data to be transmitted through a single cable, reducing the need for additional wiring. The camera also supports Web4.0, providing easy browser-based access and control, and offers a Linux SDK for custom application development.

5X Zoom outdoor IP PTZ Wifi Camera 8.0MP NOVA SONY415 Metal Housing 60M IR Distance5X Zoom outdoor IP PTZ Wifi Camera 8.0MP NOVA SONY415 Metal Housing 60M IR Distance

Imaging and Optical Specifications

Specification Details
Image Sensor 1/2.8" 30KD+ST501AI
Effective Pixel 8.0MP(3840x2160)
Video Compression H.265 Main profile / H.264 Main profile / M-JPEG
Electronic Shutter 1/25s~1/50,000s, 1/30s~1/60,000s
TV System PAL/NTSC, Progressive
Video Frame Rate 2304x1296@30fps OR 2592x1520@18fps
Min. Illumination 0.01Lux@F1.2 (AGC ON), 0Lux IR on
IR LED Nano-tech IR LED: 28µ x 10pcs, IR Range: 60M
Pan Range 0°~355°, Horizontal
Pan Speed 30°/s
Tilt Range 0°~100°, Vertical
Tilt Speed 20°/s
WDR Support ≥75dB
Quantities of Presets 128
Focal Length 2.8-12mm
Aperture F1.7-3.0
Mount M12
Focus Auto
Zoom Motorized

Network and Additional Specifications

Specification Details
Character Overlay Support channel name, date and time superposition, adjustable superposition position
TF Card Support 512G
Audio Compression Standard G711, PCM
Network Protocol TCP/IP, HTTP, DHCP, DDNS, RTP, RTSP, PPPOE, SMTP, NTP, UPNP
Interface Protocol ONVIF Hikvision XM Jovision personal protocol
P2P Android, iOS
Network Interface Built-in RJ45 network interface, support 10M/100M IP data
Application Interface Provide Linux NindoNs SDK development bag and CGI protocol can be second fast developed
Browser Support Support IE7, IE8, IE9, Chrome8+, Safari5
Ingress Protection IP67
Power Supply DC12V±10%
Working Environment -10°C~+50°C, Less than 95% RH (no condensation)
Protection Grade TVS3000V lightning protection, surge protection, voltage transient protection, weatherproof
Weight 1kg
Focal Length 2.8-12mm
Aperture F1.7-3.0
Mount M12
Focus Auto
Zoom Motorized

The 5X Optical Zoom PTZ Camera is a versatile and powerful solution for advanced surveillance needs. Its combination of high-resolution imaging, intelligent detection and tracking capabilities, robust construction, and flexible installation options make it an ideal choice for both residential and commercial applications. Whether you need to monitor large areas or focus on specific targets, this camera delivers reliable performance and superior image quality, ensuring that every detail is captured with clarity. With its advanced features and durable design, this PTZ camera provides comprehensive security coverage, making it an excellent investment for enhancing your surveillance system.
