Specifications
Brand Name :
YGHT
Model Number :
MG680K-800-20X
Certification :
CE,FCC
Place of Origin :
Shenzhen, China
MOQ :
1 PCS
Price :
Price on Application
Payment Terms :
T/T
Supply Ability :
100K PCS/Month
Delivery Time :
2-31 DAYS
Packaging Details :
26*26*43CM 3.8KG 1 / unit , 55*28*46CM 8.5KG 2 / units
Sensor Type :
1/3 inch CMOS
Optical Zoom :
25X (5.3-130mm)
IR Distance :
Up to 200 meters
Resolution :
8.0MP (NOVA + SONY415)
Compression Format :
H.265
Audio :
Two-way (Built-in Mic & Speaker)
Storage Support :
TF card, max support 512G
Software Support :
Web4.0, APP: Seetong
Special Features :
Humanoid tracking and detection, vehicle detection
Color :
White
Night Vision :
Full color night vision
Description

Introducing the cutting-edge 25X Optical Zoom PTZ Camera, offering unparalleled surveillance capabilities with advanced PTZ technology. Perfect for both residential and commercial applications, this camera combines robust features to ensure comprehensive security.

Exceptional Surveillance Capabilities

Equipped with a high-resolution NOVA + SONY415 8.0MP sensor and supporting H.265 video compression, this camera delivers clear and detailed images while optimizing bandwidth usage. Its 25X optical zoom allows for precise close-up views of distant objects, capturing fine details effortlessly.

Intelligent Monitoring Features

Experience advanced surveillance with humanoid tracking and vehicle detection, minimizing false alarms and ensuring accurate monitoring. The camera's infrared (IR) capabilities extend up to an impressive 200 meters, providing powerful night vision for round-the-clock security, even in complete darkness.

Enhanced Communication and Storage

Facilitate real-time communication with the built-in microphone and speaker system, ideal for interactive surveillance and immediate response. It supports TF cards up to 512GB, offering ample storage capacity for continuous recording without frequent data transfers.

Durable Design for All Environments

Designed to withstand various weather conditions with its IP66-rated waterproof housing, this PTZ camera is suitable for both indoor and outdoor installations. Its durable construction ensures reliable performance in challenging environments such as parking lots, industrial sites, and expansive properties.

User-Friendly Interface and Remote Access

Manage and monitor your security system effortlessly with the Web4.0 software and Seetong app. These platforms provide intuitive interfaces for easy setup, control, and remote monitoring from anywhere in the world via smartphone or tablet.

Versatile Integration and Installation

Compatible with a wide range of network protocols including TCP/IP, RTSP, and HTTPS, the camera supports seamless integration into existing security systems. It features easy installation, catering to both DIY enthusiasts and professional setups alike.

Technical Specifications:

  • Resolution: Up to 3840x2160 @ 18fps
  • Horizontal Rotation Speed: 360°
  • IR Distance: Night vision up to 300 meters
  • Power Supply: DC12V ≤ 5A, Power Consumption < 30W
  • Operating Temperature: Indoor: 0°~ +40°C; Outdoor: -40°~ +60°C
  • Certifications: CE, FCC, RoHS

OEM 25X Zoom Camera PTZ Outdoor Security Camera 200M IR Distance Humanoid Tracking

Imaging and Optical Specifications

Attribute Specification
Main Chip 1/2.8 NOVA + SONY415
Video Compression Format H.265+/H.265 Main Profile / H.264 High Profile
Maximum Resolution 3840x2160
Pixel 8.0 Megapixels
Video Resolution 3840x2160@18fps, 2592x1944@22fps, 2592x1520@25fps, 1920x1080@30fps
Focal Length 25x Optical Zoom, f=5.3~130mm
Aperture F1.4-4.3 Auto Iris
Field of View 3.8° - 72°
Minimum Illumination Color: 0.01 Lux; B/W: 0 Lux (IR LED On)
Day/Night Mode ICR Infrared Filter Switch
White Balance Auto
Auto Gain Control Auto
Signal to Noise Ratio ≥50dB (AGC OFF)
Audio Compression G711, PCM, Supports Two-Way Audio
Humanoid Tracking Supported

Network and Additional Specifications

Attribute Specification
Network Protocols TCP/IP, HTTP, NTP, IGMP, DHCP, UDP, SMTP, RTP, RTSP, ARP, DDNS, DNS, HTTPS, P2P
Software Control IE, CMS, SEETONG, ONVIF
P2P Supported
Preset Positions 128
AB Point Cruise 1 Group
Group Cruise 8 Groups (16 points per group)
Vertical Rotation Speed 0~90°
Horizontal Rotation Speed 360°
Horizontal Speed 0.1° ~ 45°/s
Vertical Speed 0.1° ~ 45°/s
LED Control Method PWM
Infrared/White Light 1. Dual Light Source: IR: 4 laser + 7 IR; White Light: 2 laser + 6 warm light<br>2. Pure Warm Light: 6 laser + 9 warm light
Infrared Distance Night Vision 300 meters
Working Temperature ≤95% Non Condensing
Power Supply DC12V ≤5A
Power Consumption < 30W
Operating Temperature Indoor: 0°~ +40°C; Outdoor: -40°~ +60°C
Lightning Protection Instantaneous 6000V
Waterproof Level IP66
Weight 5.5KG
Certifications CE, FCC, RoHS

Whether safeguarding a residence, office, warehouse, or public space, the 25X Optical Zoom PTZ Camera offers unparalleled surveillance performance with its advanced features and durable design, ensuring peace of mind and comprehensive security coverage.
