Specifications
Brand Name :
Yahong
Model Number :
YH40120
Certification :
CE / ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T , L/C , Western Union, MoneyGram
Supply Ability :
100 pcs per month
Delivery Time :
5-7 days after received your payment
Packaging Details :
lining--anti-static film package firstly, waterproof, moistureproof. Intermediate--around the perimeter of the box, there is bubble. Outer--export standard packing, fumigation-free plywood.
Product Name :
Heavy Gantry CNC Cutting Machine
Cutting Material :
Stainless steel , aluminum , iron , carbon steel
LCD Display Dimension :
10.4 inches
Effective Cutting size :
3200*10000mm
Cutting Speed :
0 - 8000 mm/min
Railway Size :
4000*12000mm
Warranty :
13 Months
Cutting Mode :
Plasma / Flame
Height Control :
Arc voltage height control
File transmission :
USB transmission
Flame Cutting Thickness :
50-150mm
Description

Heavy Gantry Aluminum Sheet CNC Gas Plasma Cutting Machine Double Drive

Description:

Heavy Gantry CNC plasma cutter is an excellent model designed and manufactured by Xuzhou Yahong CNC Equipment Factory. Accumulating several years' experience in cutting area,this series of CNC cutting machine is our latest excellent type. Human computer interface design makes the machine easy to learn and operate, and have complete functions. Equipped with functions of portable CNC cutting and can cut carbon steel, stainless steel and non-ferrous metal plate. Enable the conversion of the CAD into the program file which can be transmitted to the main machine by USB to cut plate into any shape. With two cutting modes: Flame Cutting & Plasma Cutting.

Specifications:


1. CE, ISO certificates
2. CNC control system
3. High precision,fast speed

Applications:

CNC plasma cutting machine is now widely used in industries such as machine tool manufacturing, Petro-chemical equipment, light-industrial machinery, shipbuilding, pressure vessel, mining machinery, electric power, bridge construction, aerospace, steel structure etc.

Technical Parameters for Heavy Gantry CNC Cutting Machine:

1 Cutting shape Steel plate with any plane shapes fromed by straight lines and arcs
2 LCD Display Dimension 10.4 Inches
3 Effective Cutting Size 3200*10000mm
4 Railway Size 4000*12000mm
5 Plasma Cutting Thickness 0.5--20mm ( Depends on plasma power source capacity)
6 Flame Cutting Thickness 5--150mm
7 Lifting body 1 lifting body standard
8 Cutting Speed 0-8000mm per minute
9 Height Control Electric Height Control+Arc Voltage Height Control(THC)
10 Drive Mode Bilateral drive
11 Cutting Mode flame and plasma
12 Ignition device Auto ignition device
13 File transmission USB transmission
14 Gas Pressure Max. 0.1Mpa
15 Oxygen Pressure Max.0.7Mpa
16 Cutting Gas

Flame: Oxygen+ Acetylene/ Propane/ Coal gas

Plasma :air
17 Software FastCAM Standard (support Auto CAD/ Solidworks/ CAXA/ Types etc.)
18 Cutting accuracy ±0.5mm
19 Power Supply Voltage/Frequency 220V 50HZ / 60HZ
20 Rated Power Supply 1500W
21 Working Temperature -10℃-60℃, Relative Humidity, 0-95%.

FAQ:

Q1. How to get the most suitable machine and best price?

1) Please tell me the material you want to working on.
2) What’s the MAX size of this material (Length? Width? Thickness?) .
3) Do you have any technical requirements? (Plasma power, consumables, etc.)

Q2. What shall we do if we don't know how to operate the machine after purchase?

We have detailed installation and operating instructions attached. It is very simple and we also have a 24-hour telephone and email support. And our engineers are also available for machinery service overseas but not for free.

Q3. How about your guarantee period?

One year and during the time, if you have any questions, we will solve it for free.

Packaging:

Heavy Duty CNC Sheet Cutting Machine File USB Transmission Fast Speed
