Specifications
Brand Name :
Yahong
Model Number :
YH3015
Certification :
CE / ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T , L/C , Western Union, MoneyGram
Supply Ability :
20 pcs per month
Delivery Time :
30 days after received your payment
Packaging Details :
lining--anti-static film package firstly, waterproof, moistureproof. Intermediate--around the perimeter of the box, there is bubble. Outer--export standard packing, fumigation-free plywood.
Product Name :
IPG Fiber laser cutting machine
Max cutting size :
3000×1500 mm
Max Cutting Speed :
15m/min
laser mode :
Multi mode
Laser power(W) :
500w
Working environment temperature :
-5℃-50℃
Relative humidity :
90% non-condensing
Supply frequency :
50Hz
Description

Metal Sheet 500W Fiber Laser CNC Cutting Machine With Two Years Warranty​

Description:

American IPG type fiber laser, with its excellent cutting performance of a large number of users worldwide recognition; Swiss RayToolAG company BT240 laser cutting head in authority has been in a leading brand in the field of laser cutting, its reliable cutting processing capacity is unparalleled;Shanghai BaiChu CNC system, a high degree of flexibility, general user interface, the implementation of the consistent quality and integrated remote maintenance and diagnostic function, has a friendly interface, easy to operate, good controlling, the accuracy, practicability and perfect can be diagnostic, is considered to be one of the most reliable laser cutting system existing.

Feature:

1. High strength, high rigidity box type welding machine frame, high precision linear guide and rack driving and bilateral drive system to strengthen the accuracy and stability of the machine running .

2. Integrally cast aluminum beam, strong rigidity, light weight, small inertia, fast response, machine acceleration of 0.6 G, empty moving speed of 72 m/s, improving the processing ability of the equipment. 3. Equipment machining accuracy for a long time to keep within + / - 0.05 mm.

4. No laser working gas, can save a lot of laser maintenance cost.

5. Optical fiber transmission, without reflection lens, do not need to adjust the light path.

Basic configration:

No. Description Brand Origin
1 Machine main body Yahong China
2 CNC operationg carbinet Yahong China
3 Smoke dust sucking structure Yahong China
4 air conditioning cabinet Yahong China
5 Fiber Laser IPG-500W America
6 optical module Import America
7 Conductive fiber Import America
8 QBH connector Import America
9 Laser cutting head RayToolAG Swiss
10 laser chiller Han’s China
11 CNC system Baichu China
12 Capacitive THC Baichu China
13 Servo motor Fuji Japan
14 IPC ADVANTECH Taiwan
15 Gear rack YYC/ Level 6 precision Taiwan
16 Linear Guide Bosch Rexroth Germany
17 Precision reducer Shimpo/3 Arc-min Japan
18 Proportional valve SMC Japan
19 high-pressure valve ARK Korea
20 Electronic pieces Schneider France
21 Solenoid valve SMC Japan
22 Air cylinder AirTAC Korea
23 Air Conditioner WINHENG China
24 Cutting software Baichu China
25 Composing software SmartNest China

Technical indicators:

1. Machine tool technology parameters:

Items Technical parameters
Max cutting size (mm) 3000×1500
The workpiece maximum height (mm) 90
Effective travel X axle(mm) 3050
Y axle (mm) 1550
Z axle (mm) 100
PositionaI accuracy X axle (mm/m) ±0.05/1000
Y axle (mm/m) ±0.05/1000
Z axle (mm/m) ±0.01/100
repeated positioning accuracy X axle (mm) ±0.01
Y axle (mm) ±0.01
Z axle (mm) ±0.005
Rapid positioning speed X axle (m/min) 72
Y axle (m/min) 72
Z axle (m/min) 15
Max Cutting Speed (m/min) 15
IP Grade IP54
Total weight (T) 4.35
Machine Power Consumption (Kwh) 4.8
boundary dimension L×W×H(mm) 4216×2165×1450

2. Laser & process parameters:

Items Technical parameters
working mode Continuous/modulation
Laser power(W) 500
Laser wavelength (nm) 1070
The maximum modulation frequency (KHz) 5
laser mode Multi mode
Optical quality (M2) 2.2mm*mrad
Power adjust range (%) 5-100
Fiber Length (m) 10m
Type of cooling water-cooling
Operating temperature (℃) 10-40
Long-term stability (24h) ﹤2%
Laser life(h) 100000
maximum cutting thickness MS (mm) 6
SS(mm) 2
cutting speed (1mm MS) 15m/min
Focal length F(mm) 150
Adjustable focus range (mm) 0-10
Overall Power Consumption (Kwh) 4

Cutting Samples:

High Strength Industrial CNC Laser Cutter Box Type Design Safety Assured Bilateral Drive System
