Specifications
Brand Name :
Yahong
Model Number :
YH1530
Certification :
ISO / CE
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
200pcs per month
Delivery Time :
7 days after received your payment
Packaging Details :
lining--anti-static film package firstly, waterproof, moistureproof. Intermediate--around the perimeter of the box, there is bubble. Outer--export standard packing, fumigation-free plywood.
Product Name :
Portable CNC Cutting Machine
Cutting Mode :
Plasma / Flame
Cutting Speed :
0-4000mm/min
Effective Cutting size :
1500*3000mm
Railway Size :
2000*3500mm
Height Control :
Arc voltage height control (THC) or Electric adjustable high
Power Supply Voltage/Frequency :
220 V 50HZ / 60HZ
Cutting precision :
±0.5mm National standard JB/T10045.3-99
Description

Fastcam Software Cnc Automated Plasma Cutter Arc Voltage Height Control

Description:

1. Portable CNC flame and plasma cutting machine is a kind of high efficiency energy-saying cutting equipment, smart design, can be moved everywhere you need.

2. It is widely used in all kinds of carbon materials,stainless steel and nonferrous metal sheet and thick metal plate. with the power adjustment block device and auto height controller.
3. Cross beam adopt special aluminum alloy industrial, light weigh and no deformation.

4. The control system can support many kinds of language,simple operation,smart cut,cut all shapes from USB.

Features:

1. Good Working stability, high frequency interfere effectively plasma, lightweight portable.

2. Support two cutting ways of flame and plasma.

3. Economic benefits, the structure and design is contracted. it adopts humanistic positive man-machine conversation and operate easily.

4. Cutting has high quality, high effect level, high precision.

5. Programmable cutting arbitrary shape parts of line and arc.

7. This product is a portable CNC cutting machine can cut any complex plane graphics, support flame, plasma cutting. Reduce the secondary processing, improve production efficiency.


Technical Parameters for Portable CNC Cutting Machine:

1 Cutting shape any shapes
2 LCD Display Dimension 7.0Inches
3 Effective Cutting Width (X axis) 1500mm
4 Effective Cutting Length (Y axis) 3000mm
5 Cross Beam Length 2000mm
6 Longitudinal Rail Length 3500mm
7 Cutting Speed 0-4000mm per minute
8 Plasma Cutting Thickness 0.5--20mm ( Depends on plasma power source capacity)
9 Flame Cutting Thickness 5--200mm
10 Drive Mode single-side
11 Cutting Mode flame and plasma
12 Ignition device Auto ignition device
13 Height regulating device Arc voltage height control (THC) or Electric adjustable high
14 File transmission USB transmission
15 Gas Pressure Max. 0.1Mpa
16 Oxygen Pressure Max.0.7Mpa
17 Cutting Gas Acetylene/Propane
18 Plasma Power Source Yahong cut-100A,cut-130A, cut-200A or other
19 Plasma Air Only pressed Air
20 Software FastCAM Standard vision(support Auto CAD/ Solidworks/ CAXA/ Types etc.)
21 Plasma Air Pressure Max. 0.8Mpa
22 Cutting precision ±0.5mm National standard JB/T10045.3-99
23 Control accuracy ±0.01mm
24 Power Supply Voltage/Frequency 220V 50HZ / 60HZ
25 Rated Power Supply 200W
26 Working Temperature -10℃-60℃, Relative Humidity, 0-95%.

































Cutting Samples:
