0.6 1kV 4 Core Low Voltage Cable , Steel Wire Armoured XLPE Cable Construction Use
0.6 1kV 4 Core Low Voltage Cable , Steel Wire Armoured XLPE Cable Construction Use
0.6 1kV 4 Core Low Voltage Cable , Steel Wire Armoured XLPE Cable Construction Use
0.6 1kV 4 Core Low Voltage Cable , Steel Wire Armoured XLPE Cable Construction Use
0.6 1kV 4 Core Low Voltage Cable , Steel Wire Armoured XLPE Cable Construction Use
0.6 1kV 4 Core Low Voltage Cable , Steel Wire Armoured XLPE Cable Construction Use
0.6 1kV 4 Core Low Voltage Cable , Steel Wire Armoured XLPE Cable Construction Use
0.6 1kV 4 Core Low Voltage Cable , Steel Wire Armoured XLPE Cable Construction Use
Specifications
Brand Name :
YIFANG
Model Number :
YJV, YJLV, ZR-YJV, ZR-YJLV
Certification :
ISO9001, ISO18001, OHSAS
Place of Origin :
CHINA
MOQ :
500meters
Price :
USD0.1/m to USD 25/m
Supply Ability :
5000km per week
Delivery Time :
3-20 work days
Packaging Details :
Cable can be supplied in any length required.
Payment Terms :
L/C, T/T
Conductor :
Aluminum Copper
Insulation :
XLPE
No. of core :
1, 2, 3, 4, 5 Core
Voltage :
0.6 1KV
Usage :
Construction
Armoured :
Steel Tape
Description

0.6 1kV 4 Core Low Voltage Cable , Steel Wire Armoured XLPE Cable Construction Use

1. Application:


XLPE insulated power cable has a number of advantages over paper insulated and PVC insulated cable. XLPE cable has high electric strength, mechanical strength, high-ageing resisting, environmental stress resisting aiti-chemical, corrosion, and simple construction, using convenient and higher operating of long term temperature. It can be laid with no drop restriction.


Various of flame-retardant XLPE cable can be manufactured with three technology .The flame-retardant cable covers all kinds of low-smoke, halogen free, and non-smoke non-halogenated and three classes of A,B,C.

2. Construction:


Scope of XLPE cable


Type No. of Core Nominal cross-section

Type No. of Core Nominal cross-section

Cu(AL)/XLPE/PVC(PE)

Cu(AL)/XLPE/ATA/PVC(PE)Cu(AL)/XLPE/AWA/PVC(PE)

 1 1.5-1000

Cu(AL)/XLPE/STA/PVC(PE)

Cu(AL)/XLPE/SWA/PVC(PE)

 2,3,4,5 1.5-400
3+1,4+1,3+2 2.5-400

3. Voltage test:


Each drum of finished cable should withstand power frequency voltage 3.5kV for 5 minutes,the insulation is not breakdown.
Service conditions and operation parameters of Cable:
The cable is applied to fixed installation for rated voltage 0.6/1kV of power transportation and distribution line.
Max. rated temperature of conductor. nominal operating 90℃
Short circuit: max. for 5 sec.250℃
The cable can be laid without drop restriction, and the environment temperature shall not be lower than 0℃.


4. Standard:
Our XLPE cable can be manufactured according to the company’s specification which is equivalent to IEC 60502,IEC60332,IEC60754.
Some indexes are superior to above international standard.
