XLPE SWA PVC Power Cable Single Core With Aluminium Or Copper Conductor
XLPE SWA PVC Power Cable Single Core With Aluminium Or Copper Conductor
Specifications
Brand Name :
yifang
Model Number :
YJV32 SWA
Certification :
CE UL KEMA
Place of Origin :
China
MOQ :
500 meters
Supply Ability :
50000 km per year
Delivery Time :
20 days
Packaging Details :
Wooden drum steel-wooden drum all steel drum
Description

Steel Wire Armoured Cable

XLPE SWA PVC Power Cable Single Core With Aluminium Or Copper Conductor

NYY,NAYY,YVV,NYCY,NYRY,NA2XY,YE3SV,YE2SHSV,NAYCVVY,NA2XY,N2XY,N2XRY Cable

Voltage:0.6/1kV,3.6/6kV;6/10KV;8.7/15KV;12/20KV;18/20KV;21/35KV;26/35KV

Conductor:
Solid or stranded Copper/Aluminum

- Insulation:
Cross-linked polyethylene( XLPE or PVC)
- Circuit Indentation:
The insulation shall be red, black
- Filler:
Polypropylene lament with lapped binding tape
-I nner Sheath:
Polyvinyl chloride (Black)
- Armor:
Galvanized steel wire/steel tape/Unarmored/Aluminum wire
- Core-covering:
Binding tape
- Outer Sheath:
Polyvinyl chloride (Black)

- Application:
For use in ducts, trays and direct burial in ground. The cable is subject to immerse in water all the time.
- Standards:
IEC 60502-1

3. Specification:

Type Designation Application
VV Copper conductor ,PVC insulated ,PVC sheathed power cable For laying indoors, in tunnel or cable trench,unable to bear extermal mechanical forces. Single core cable is not permissible to lay in magnetic duct
VLV Aluminium conductor ,PVC insulated ,PVC sheathed power cable
VY Copper conductor, PVC insulated, PE sheathed power cable
VLY Aluminium conductor ,PVC insulated ,PE sheathed power cable
VV22 Copper conductor ,PVC insulated ,steel tape armoured ,PVC sheathed power cable For laying indoors, in cable trench or direct in ground ,able to bear external mechanical forces, but unable to bear pulling force
VLV22 Aluminium conductor ,PVC insulated ,steel tape armoured ,PVC sheathed power cable
VV23 Copper conductor ,PVC insualted ,steel tape armoured ,PE sheathed power cable
VLV23 Alunminium conductor ,PVC insulated ,steel tape armoured ,PE sheathed power cable
VV32

Copper conductor, PVC insulated, steel wire armoured,PVC insulated power cable

 For laying indoors, in cable or direct in ground ,able to bear external mechanical forces, but unable to bear large pulling forces
VLV32 Aluminium conductor, PVC insulated ,steel tape armoured ,PVC sheathed power cable
VV33 Copper conductor, PVC insulated steel wire armoured , PE sheathed power cable
VLV33 Aluminium conductor , PVC insulated , streel wire armoured ,PE sheathed power cable
Note: The armoured single core cables is only used for D.C.system. As for A.C.system,non-magnetic armored material should be applied

4. Nominal Cross-sectional Areas:

1.5 mm2 , 2.5 mm2 ,4 mm2 , 6 mm2 , 10 mm2 , 16 mm2 ,25 mm2 , 35 mm2 , 50 mm2 ,70 mm2 , 95 mm2 ,120 mm2 ,150 mm2 ,185 mm2 ,240 mm2 ,300 mm2 400 mm2 500 mm2 630 mm2 800 mm2

5. Production Range:

single core cable from 1.5 mm2 to 800 mm2,muli-core cable from 1.5 mm2 to 400 mm2

6. Operating Characteristics:

Rated power-frequency voltage u0/u:0.6/1 KV 3.6/6KV 12/20KV 18/35KV...

Max permissible continuous operating temperature of conductor 70

Max short-circuit temperature of the conductor shall not exceed (Max 5 seconds duration): cross-section of conductor 300 mm2

The ambient temperature under installations should not be below 0

The bending radius of single core cable should not be less than 20 times of the cable diameter ,the bending radius of multi-core cable should not be less than 15 times of the cable diameter.
