XLPE Medium Voltage Cables MV Copper Conductor SWA 33kV X 70mm2 X 3 C
XLPE Medium Voltage Cables MV Copper Conductor SWA 33kV X 70mm2 X 3 C
Specifications
Brand Name :
Yifang
Model Number :
YJV32
Certification :
KEMA
Place of Origin :
China
MOQ :
500meters
Price :
USD 30--35 per meter
Supply Ability :
80km per month
Delivery Time :
3weeks
Packaging Details :
Iron-wooden drum
Conductor :
Copper
Standard :
IEC60502-2
Core :
Three
Code :
NA2XFY
Description

XLPE Medium Voltage Cables MV Copper Conductor SWA 33kV X 70mm2 X 3 C

1. Introduction

For XLPE insulated power cable, either chemical method or physical method is employed to transform the molecular structure of PE from chain into three-dimensional network, i.e. thermo-plastic PE is transformed into thermosetting XLPE. After cr·oss-linking, the thermal and mechanical properties of PE have been greatly improved while its excellent electrical property are still retained.

The maximum permissible operating of the conductor of a XLPE insulated power cable is 90°C.which is higher than that of paper, PVC or PE insulated power cable. The cable has the advantage of simplicity in construction, lightness in weight, convenience in application besides its excellent electrical, thermal, mechanical and anti-chemical corrosion properties. It can also be laid with no limitation of level difference along the route.

2 The product is manufactured according to the standard of IEC60502-2,BS,DIN and ICEA upon request.

3 .The product is suitable for use in power transmission and distribution lines with rated power frequency voltage18/30(33)kv.

4. Instruction of application

4.1 Rated voltages: 18/30 (33)kv.

4.2 The ambient temperature for installation: ≥0°C

4.3 Maximum conductor temperature in normal operation:≤90°C

4.4 Max operating temperature of con. When cable short-circuited (5s maximum duration): 250°C

4.5 Permissible bending radius:

Multi cable:[12(D+d) ±5%] mm
