34.4mm2 Overhead Aluminium Alloy Almelec Cable With 7,19,37,61,91 Strands
34.4mm2 Overhead Aluminium Alloy Almelec Cable With 7,19,37,61,91 Strands
34.4mm2 Overhead Aluminium Alloy Almelec Cable With 7,19,37,61,91 Strands
34.4mm2 Overhead Aluminium Alloy Almelec Cable With 7,19,37,61,91 Strands
34.4mm2 Overhead Aluminium Alloy Almelec Cable With 7,19,37,61,91 Strands
34.4mm2 Overhead Aluminium Alloy Almelec Cable With 7,19,37,61,91 Strands
Specifications
Brand Name :
Yifang Cable
Model Number :
JKLH
Certification :
CE,ISO,UL,KEMA
Place of Origin :
China
MOQ :
1km
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram, D/A, D/P
Supply Ability :
500km per month
Delivery Time :
5-8working days
Packaging Details :
Wooden drum 1.1mx0.8mx1.1m, Wooden Steel Drum2.2mx1.45mx2.2m
Size :
54.6,93.3,117,228,288,336,507mm2
Standard :
NFC 34 215,EN 50182
material :
Aluminum Alloy
application :
overhead lv or mv power line
Coutry :
Senegal,Madagascar,Congo,Burkina Faso
Strands :
7,19,37,61
Description

34.4mm2 Overhead Aluminium Alloy Almelec Cable With 7,19,37,61,91 Strands

Quick Details

· Place of Origin: Henan, China (Mainland)

· Brand Name: Zhengcable

· Model Number: almelec cable with 7,19,37,61,91strands

· Insulation Material: none

· Type: HV MV LV

· Application: Overhead

· Conductor Material: Aluminium alloy

· Jacket: None

· advantage: Resistance chemical corrosion

· advantage1: anti heat-ageing,environment stress

· advantage2: light in weight

· advantage3: especially for laying across

DESCRIPTION

Utilisation

Ces Câble almelec font preuve de nombreux

avantages : la légèreté, une charge de rupture haute permettant de longues portées,la simplicité des accessoires et enfin le recyclage facile. Ces conducteurs conviennent aux réseaux de longue portée.

Mode de pose

A l'air libre

Norme : NF C 34- 125, EN 50182, IEC 61089

Packaging & Delivery

Packaging Details: wooden drum;wooden_iron drum;iron drum.
Delivery Detail: sample(3d);in stock(10d);general cargo(15d);OEM/ODM(20d)

Product Description

All aluminium alloy conductor, aaac cable with BS,ASTM,DIN,IEC standard

1 Description of aaac cable

Aluminium alloy 6201 wires, concentrically stranded from 7 strands to 91 strands depending upon the size.

ITEM DESCRIPTION UNITS OFFER BIDDER
1 manufacturer ‐ Zhengzhou yifang cable co.ltd
1.1 Type Model No ‐ Almelec 34.4mm2
1.2 Country of origin ‐ China
2 Structure ‐ 　
2.1 nominal section mm² 34,4
2.2 Number no. 7
2.3 Nominal diameter Diameter of single wire mm 2, 5
2.4 Conductor diameter mm 7,5
3 MECHANICAL PROPERTIES AND ELECTRICAL 　 　
3.1 Mass per unit length of the cable Kg/Km 93
3.2 Breaking load daN 1105
3.3 Modulus of elasticity Hbar 6000
3.4 Resistance at 20 ° C Ohm/km 0,958
4 Standards 　 NFC 34-125 IEC 61089

34.4mm2 Overhead Aluminium Alloy Almelec Cable With 7,19,37,61,91 Strands

34.4mm2 Overhead Aluminium Alloy Almelec Cable With 7,19,37,61,91 Strands
