Yifang Cable Bare Aluminum Alloy Aster Conductor Almelec Conductor 366mm2
Yifang Cable Bare Aluminum Alloy Aster Conductor Almelec Conductor 366mm2
Specifications
Brand Name :
Yifang Cable
Model Number :
JKLH
Certification :
CE,ISO,UL,KEMA
Place of Origin :
China
MOQ :
1km
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram, D/A, D/P
Supply Ability :
500km per month
Delivery Time :
5-8working days
Packaging Details :
Wooden drum 1.1mx0.8mx1.1m, Wooden Steel Drum2.2mx1.45mx2.2m
Size :
54.6,93.3,117,228,288,336,507mm2
Standard :
NFC 34 215,EN 50182
material :
Aluminum Alloy
application :
overhead lv or mv power line
Coutry :
Senegal,Madagascar,Congo,Burkina Faso
Strands :
7,19,37,61
Description

Yifang Cable Bare Aluminum Alloy aster conductor Almelec Conductor 366mm2

French Standard Aluminum Alloy Bare Almelec Cable with BS,ASTM,DIN,IEC standard

Quick Details

· Place of Origin: Henan, China (Mainland)

· Brand Name: Zhengcable

· Model Number: almelec cable with 7,19,37,61,91strands

· Insulation Material: none

· Type: HV MV LV

· Application: Overhead

· Conductor Material: Aluminium alloy

· Jacket: None

· advantage: Resistance chemical corrosion

· advantage1: anti heat-ageing,environment stress

· advantage2: light in weight

· advantage3: especially for laying across

Packaging & Delivery

Packaging Details: wooden drum;wooden_iron drum;iron drum.
Delivery Detail: sample(3d);in stock(10d);general cargo(15d);OEM/ODM(20d)

Product Description

All aluminium alloy conductor, aaac cable with BS,ASTM,DIN,IEC standard

1 Description of aaac cable

Aluminium alloy 6201 wires, concentrically stranded from 7 strands to 91 strands depending upon the size.

TECHNICAL DATA SHEET
Câble Almélec 366 mm² ASTER
NO DESCRIPTION UNIT DATA
1 Type/ code name -- Almelec 366
2 Material -- Aluminium Alloy
3 Standards -- IEC 61089,NFC 34 125,NF EN 50182
4 Cross Section Area mm2 366
5 Conductor construction 　 　
　 Wire No. No.s 37
　 Nominal wire dia. mm 3.55
6 Approx. Overall Diameter mm 24.84
7 Approx. Weight kg/km 999
8 Min.Breaking Load kN 111.6
9 Max. D.C. Resistant 20℃ Ω/km 0.0915

Yifang Cable Bare Aluminum Alloy Aster Conductor Almelec Conductor 366mm2
