15 - 35kV Medium Voltage Power Cables Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution
15 - 35kV Medium Voltage Power Cables Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution
Specifications
Brand Name :
Yifang
Model Number :
YJLY
Certification :
ISO, CE, KEMA, SGS
Place of Origin :
China
MOQ :
1000m
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
30,000KM Per Year
Delivery Time :
4 to 8 weeks
Packaging Details :
Wooden Drums, Steel-wooden Drums, Steel Drums
Voltage :
15-35kV
Conductor :
Aluminum
Insulation :
XLPE
Shield :
Copper Wire
Sheath :
PE
Description

15-35kV Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution

Applicable standards:

IEC60502, BS6622, SANS1339, AS/NZS1429.1, DIN VDE 0276-626, NFC 33-226, IEC60840, ICEA S-93-639. ICEA S-94-649

Production Scope:
a) National standard

Rated Voltage (kV) Cores 3.6/6 6/6 6/10 8.7/10 8.7/15 12/20 18/20 18/30 21/35 26/35
Cross-section (mm2) 1C 25-800 25-800 25-800 35-800 35-800 35-800 35-800 35-800 35-800 35-800
Cross-section (mm2) 3C 25-400 25-400 25-400 35-400 35-400 35-400 35-400 35-400 35-400

35-400

b) ICEA standard

Rated Voltage (V) Cores 5001-8000 8001-15000 15001-25000 25001-28000 28001-35000 35000-46000

Cross-section

(AWG or kcmil)

 1C

6AWG～

1600kcmil

2AWG～

1600kcmil

 1AWG～1600kcmil 1AWG～1600kcmil

2AWG～

1600kcmil

1/0AWG～

1600kcmil

Cross-section

(AWG or kcmil)

 3C 6AWG～800kcmil 2AWG～800kcmil 1AWG～800kcmil 1AWG～800kcmil 2AWG～800kcmil

4/0AWG～

800kcmil

Construction:

Core 1core or 3cores
Conductor Bare Copper or Aluminum
Conductor Screen Semi-conducting compound
Insulation XLPE
Insulation Screen Semi-conducting compound
Shield Copper wire/ Copper tape/AL-Plastic tape
Inner Sheath( optional) PVC/ PE/ LSZH
Armoured ( optional) Galvanized steel wire/Aluminum wire/Two layers of Aluminum tape gap-wrapped /Two layers of steel tape gap-wrapped / Galvanized steel interlocked armour/Aluminum alloy interlocked
Outer Sheath PVC/ PE/ LSZH


Packing Details:

Wooden drums,steel drums or steel-wooden drums or according to your request.

Cerfications:

15 - 35kV Medium Voltage Power Cables Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution15 - 35kV Medium Voltage Power Cables Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution

Factory Pictures:

15 - 35kV Medium Voltage Power Cables Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution15 - 35kV Medium Voltage Power Cables Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution

15 - 35kV Medium Voltage Power Cables Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution

Loading Containers:

15 - 35kV Medium Voltage Power Cables Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution15 - 35kV Medium Voltage Power Cables Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution15 - 35kV Medium Voltage Power Cables Aluminum Conductor XLPE Insulation PE Sheath Underground Distribution

We can design and produce according to client's requirement. Welcome to contact us for any more information!
