Copper High Voltage Power Cable 15kV 33kV XLPE Insulated Armored Power Cable
Copper High Voltage Power Cable 15kV 33kV XLPE Insulated Armored Power Cable
Copper High Voltage Power Cable 15kV 33kV XLPE Insulated Armored Power Cable
Copper High Voltage Power Cable 15kV 33kV XLPE Insulated Armored Power Cable
Copper High Voltage Power Cable 15kV 33kV XLPE Insulated Armored Power Cable
Copper High Voltage Power Cable 15kV 33kV XLPE Insulated Armored Power Cable
Specifications
Brand Name :
Yifang Cable
Model Number :
YJV32
Certification :
CE,ISO,KEMA
Place of Origin :
China
MOQ :
1000M
Price :
USD1-10/m
Payment Terms :
T/T, L/C
Supply Ability :
300km/month
Delivery Time :
15days
Packaging Details :
steel-wooden drum
Conductor :
Copper or Aluminum
Insulation :
XLPE
Inner sheath :
PVC
Armour :
Steel wire
Sheath :
PVC
Description

Copper High Voltage Power Cable 15kV 33kV XLPE Insulated Armored Power Cable

Application:XLPE Cable is used indoor or outdoor, in tunnel, cable furrow or pipe, to be laid underground, be applicable to the well, water inside and fall in the bad soil.

Standards:IEC60502-2, BS7870-4, BS7870-7, BS7870-8

Cores: 1 Core, 3 Core

Conductor:Cu or Aluminum

Insulation:XLPE (Cross-Linked Polyethylene)

Armor:non-armor, steel tape armored, steel wire armored

Sheath:PVC or PE

Sheath Color:Black or Colors

Product Description:
- XLPE insulated PVC sheathed power cable (XLPE/PVC Cable)
- XLPE insulated steel tape armored PVC sheathed power cable (XLPE/STA/PVC Cable)
- XLPE insulated steel wire armored PVC sheathed power cable (XLPE/SWA/PVC Cable)
- Flame retardant XLPE insulated PVC sheathed power cable (FR/XLPE/PVC Cable)
- Flame retardant XLPE insulated steel tape armored PVC sheathed power cable (FR/XLPE/STA/PVC Cable)
- Flame retardant XLPE insulated steel wire armored PVC sheathed power cable (FR/XLPE/SWA/PVC Cable)
FR – Flame Retardant


26/35kV Three Cores Copper ConductorXLPE Insulated Steel Wire Armored PVC sheathed Power Cable
26/35kV Three Cores Cu/XLPE/STA/PVC Power Cable

Nominal cross section
mm2		 Insulation
Thickness
mm		 Approx. Overall Dia.& Weight
Steel Tape
layer×thickness		 PVC sheath PE sheath
Overall dia.
mm		 Weight
kg/km		 Overall dia.
mm		 Weight
kg/km
50 10.5 2x0.8 89.0 8791 89.0 8326
70 10.5 2x0.8 93.1 9878 93.1 9377
95 10.5 2x0.8 97.0 11079 97.0 10530
120 10.5 2x0.8 100.5 12238 100.5 11655
150 10.5 2x0.8 104.4 13597 104.4 12976
185 10.5 2x0.8 108.1 15050 108.1 14391
240 10.5 2x0.8 114.0 17386 114.0 16658
300 10.5 2x0.8 118.8 19710 118.8 18934
400 10.5 2x0.8 126.6 23603 126.6 22722

More types of Cu/XLPE/SWA/PVC Power Cable, Please contact us. We will reply ASAP.
