Android parameters:

Operating system:Android 5.1

Processor (CPU): 4-core ARM® Cortex-A17, clocked at 1.6GHz

Graphics Processing Unit (GPU): ARM Mali-T764 3D GPU

Support OpenGL ES1.1/2.0, OpenVG1.1

Resolution: 1920*1080P

Operation/Storage: DDR4 2GB/16GB

Video camera

Sensor: 1/2.8 inch CMOS, effective pixels: 2.07 million

Lens: Optical 10X, f=4.7mm ~ 47mm, F1.5 ~ F2.5

Minimum illumination: Color: 0.1Lux

Shutter: 1/60-1/10000S

White balance: auto/indoor/outdoor

Backlight compensation: support

Signal to noise ratio: ≥55dB

Horizontal field of view: 58°

Horizontal rotation range: ±175° Vertical rotation range: 90° (upward), 45° (downward)

Horizontal rotation speed range: 1°~60°/s

Vertical rotation speed range: 1°~60°/s

Vertical flip: support

interface

Audio input interface: 1 x 3.5mm microphone input (optional)

Audio output interface: 1 x 3.5mm linear output (optional)

Video input interface: 1 x built-in camera input

1 X USB*2

Video output interface: 1 x HDMI 2.0 (Type-A ), support 4K@60 frame output

USB interface: 3x USB2.0

Network interface: 1 x RJ45: 1 x 10/100/1000 Mbps 1 x wireless: 2.4G/5G WiFi dual-band WIFI 1 x Bluetooth 4.0 SD card por 1 TF/Micro SD card port maximum support 128G TF card

Power interface: 1 x 12V/2A DC power interface

General characteristics

Terminal size: 284mm*147mm*161mm

Working voltage: AC 100V ~ 240V, DC 12V

Working frequency: 50Hz/60Hz

Maximum power consumption: 24W

Temperature: 0°C ~ 40°C (working state), -40°C ~ 70°C (non-working state)

Relative humidity: 10% ~ 80% (working state), 0% ~ 95% (non-working state)

Surrounding noise: less than 46dBA SPL

Minimum illumination: 5lux

Recommended illuminance: greater than 300lux

Product Features:

Integrated platform integration design: support one HDMI output; support LAN interface; support 3 USB2.0 interfaces; support 2.4G/5G WiFi; support Bluetooth connection, which realizes the integration of camera and conference terminal platform;

RK3288 processor: Super quad-core Cortex-A17, frequency 1.6GHz CPU

Image processing: support OPENGL ES1.1/2.0/3.0, OPEN VG1.1, OPENCL, Directx11, embedded high-performance 2D/3D acceleration hardware, support 4K, H.265 hard decoding 10bits color depth, HDMI2.0, support 1080P Multi-format video decoding 1080P video encoding, supporting H.264, VP8 and MVC image enhancement processing

Sophisticated design: adopts an integrated compact design with a built-in camera. Small size, rich interface, convenient connection, simple installation and maintenance;

Wireless WiFi: Support standard wireless protocols, simple and efficient device deployment;

Local storage: support SD card storage, U disk storage, storage space up to 64G;

HD lens: 10x optical zoom, 58° horizontal angle of view, no distortion lens; Low noise and high signal-to-noise ratio:

Low-noise CMOS effectively guarantees the ultra-high signal-to-noise ratio of the camera video

. Adopt advanced 2D and 3D noise reduction technology to further reduce the noise while ensuring image clarity;

Multiple video compression standards: support MJPEGH/H.264 video compression; Low-power sleep function: support low-power sleep/wake up;

There are many applications: conferences, education, medical care, government affairs, cloud video, collaborative office, multimedia integration, emergency command, broadcasting, justice, public security, military and other system applications
