Specifications
Brand Name :
YouNatural
Model Number :
YNT20D
Place of Origin :
CHINA
Certification :
UL1973, IEC62619,UN38.3, UN3536
MOQ :
1
Price :
Negotiation
Delivery Time :
Negotiation
Payment Terms :
L/C, D/A, D/A, D/P, T/T, Western Union, Western Union, MoneyGram
Supply Ability :
500 Set/Sets per Month
Product Name :
Energy Storage Container-YNT20D
Battery cell type :
LFP, 3.2V/280Ah
Nominal energy (BOL) :
1505kWh
Nominal voltage :
768VDC
Battery voltage range :
648~840VDC
Charging /Discharging mode :
CP
Degree of protection :
IP54
Operation temperature :
-20~+45℃
Storage temperature :
-30~+50℃
Altitude :
≤2000m
Relative humidity :
5%~95% (No condensing)
Dimension(W*D*H) :
6096*2438*2591mm
Weight :
23T
Description

Product Description:

The Energy Storage Container is an advanced battery energy storage system container, designed to provide a highly efficient, safe, and reliable energy storage solution. It provides an all-in-one solution for energy storage that can be deployed quickly and with minimal disruption to the environment. The Energy Storage Container features a robust communication system, including CAN and RS485, and is equipped with a fire alarm and dry pipe fire extinguishing system to ensure safety. The Energy Storage Container is an ideal choice for container energy storage systems (ESS) and is an excellent option for energy storage.

Features:

  • Product Name: Energy Storage Container
  • Rated voltage: 400VAC
  • Grid switching time: <20ms
  • Protection value: IP54
  • Dry pipe fire extinguishing: Yes
  • Weight MT: 23T
  • Renewable Energy: Yes
  • Energy Storage Container: Yes
  • Container Battery for ESS Energy Storage System: Yes

Technical Parameters:

Model:500kW/1505kWh Specification
AC Parameters Rated power 550kW
Max. power 550kW
Rated current 720A
AC Max. current 792A
THDi <3%
Rated voltage 400VAC
Voltage range 360~440V (utility-interactive mode)
Rated frequency 50Hz/60Hz
AC PF 0.1~1 leading or lagging
Isolation Non-isolation(Isolation transformer is optional)
Wire type 3P4W+PE
DC Parameters Battery cell type LFP, 3.2V/280Ah
Nominal energy (BOL) 1505kWh
Nominal voltage 768VDC
Battery voltage range 648~840VDC
Charging /Discharging mode CP
Other Parameters Degree of protection IP54
Operation temperature -20~+45℃
Storage temperature -30~+50℃
Altitude ≤2000m
Relative humidity 5%~95% (No condensing)
Cooling Independent temperature control,air- conditioning cooling
Fire suppression system FM-200 (Novec 1230 optional)
Communication MODBUS
Dimension(W*D*H) 6096*2438*2591mm
Weight 23T
Certification UL1973, IEC62619,UN38.3, UN3536

Applications:

YouNatural's YNT industrial container energy storage solution is a reliable and cost-effective way to power up your industry. It is UL1973, IEC62619, UN38.3 and UN3536 certified and has a minimum order quantity of 1. The price and delivery time are negotiable. There are various payment terms, such as L/C, D/A, D/A, D/P, T/T, Western Union, Western Union, MoneyGram. With a supply ability of 500 Set/Sets per month, it is a reliable and efficient choice. The fire alarm is available and it supports CAN and RS485 communication. It has a battery cluster capacity of 720A andRated voltage of 400VAC.

This industrial container energy storage solution is perfect for storing solar energy, making it ideal for industry use. It is easy to install and maintain. It offers consistent performance and is highly reliable. With its ability to provide efficient and reliable energy storage, this container energy storage solution helps industries operate in a safe and secure environment. It is also highly efficient and cost-effective, making it the best choice for industry energy storage needs.

Support and Services:

Technical Support and Service for Energy Storage Container

We provide technical support and service for our Energy Storage Container product line. Our experienced technicians are on hand to provide you with the best service possible and ensure your product is working optimally.

We offer a wide range of services, such as:

  • Installation and configuration
  • Troubleshooting and repairs
  • Performance tuning
  • Upgrades and maintenance
  • Diagnostics and troubleshooting
  • Data recovery
  • Consulting and training

We stand behind our products and have a commitment to providing excellent customer service. If you have any questions or concerns, please don't hesitate to contact us. We are here to help!

FAQ:

A1: The brand name of the Energy Storage Container is YouNatural.

A2: The model number of this Energy Storage Container is YNT.

A3: This Energy Storage Container is manufactured in China.

A4: This Energy Storage Container has UL1973, IEC62619,UN38.3 and UN3536 certifications.

A5: The minimum order quantity for the Energy Storage Container is 1.
