SX011836 Crossed Roller Bearings180x225x22mm Replace INA brand machine tool use
SX011836 Crossed Roller Bearings180x225x22mm Replace INA brand machine tool use
SX011836 Crossed Roller Bearings180x225x22mm Replace INA brand machine tool use
SX011836 Crossed Roller Bearings180x225x22mm Replace INA brand machine tool use
SX011836 Crossed Roller Bearings180x225x22mm Replace INA brand machine tool use
SX011836 Crossed Roller Bearings180x225x22mm Replace INA brand machine tool use
SX011836 Crossed Roller Bearings180x225x22mm Replace INA brand machine tool use
SX011836 Crossed Roller Bearings180x225x22mm Replace INA brand machine tool use
Specifications
Brand Name :
YDPB
Model Number :
SX011836
Place of Origin :
Luoyang，China
MOQ :
1PCS
Price :
1$
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000pcs/month
Delivery Time :
5-7days
Packaging Details :
bearing+thin plastic film+waterproof paper+thin foam+carton/wooden cases
Certification :
ISO
Model :
SX011836
Material :
GCr15
Structure :
Crossed Cylindrical Roller bearings
Dimension :
180x225x22mm
Application :
Robots arm/machine tool
Name :
Cross-roller bearing
Description

SX011836 Crossed Roller Bearings 180x225x22mm High precision Robotic arm use

Crossed Roller Bearings Parameters

Model number- SX011836

Inner ring(mm)- 180

Outer ring(mm)- 225

Width(mm)- 22

Weight(Kg)-2.3

Materials- GCR15/GCR15SiMn

Precision grade- P5/P4/P2

Lubrication type- Grease lubrication

Rotating part- Inner Ring Rotation

Load direction- Multi-load

Structure- Outer ring split

Main parameters

SX011836 Crossed Roller Bearings180x225x22mm Replace INA brand machine tool use

Identification number Main dimensious shoulder height Basic load rating (axial) Basic load rating (radial) weight
Inner diameter outer diameter Roller pitch circle diameter width Greasing hole r de Di Ca Coa Cr Cor Kg
d D Dp B/B1 S KN KN KN KN
SX011814 70 90 80 10 1.2 0.6 79.5 80.5 18 60 12 30 0.3
SX011818 90 115 102 13 1.2 1 101.5 102.5 26 96 17 47 0.4
SX011820 100 125 112 13 1.2 1 111.5 112.5 28 106 18 52 0.5
SX011824 120 150 135 16 1.5 1 134.4 135.6 41 153 26 75 0.8
SX011828 140 175 157 18 1.5 1.1 156.3 157.7 64 237 41 116 1.1
SX011832 160 200 180 20 1.5 1.1 179.2 180.8 69 272 44 133 1.7
SX011836 180 225 202 22 2 1.1 201.2 202.8 98 381 63 187 2.3
SX011840 200 250 225 24 2 1.5 224.2 225.8 106 425 68 208 3.1
SX011848 240 300 270 28 2 2 269.2 270.8 149 612 95 300 5.3
SX011860 300 380 340 38 2.5 2.1 339.2 340.8 245 1027 156 504 12
SX011868 340 420 380 38 2.5 2.1 379.2 380.8 265 1148 167 563 13.5
SX011880 400 500 450 46 2.5 2.5 449 451 385 1699 244 833 24
SX0118/500 500 620 560 56 2.5 3 558.8 561.2 560 2538 355 1244

44

Drawings and other parameters ,pls contact us free, thanks

Market:
After years of development ,our products have been sent out to Germany ,Italy, Spain, Romania,Belgium,Israel,Russia,Korea,Mexico,India etc. Good quality and Service earn the constant supports from all our customers. any of your questions will be welcomed here any time.
