Specifications
Brand Name :
YDPB
Model Number :
XI 140575N
Certification :
ISO
Place of Origin :
Luoyang，China
MOQ :
1PCS
Price :
1$
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000pcs/month
Delivery Time :
5-7days
Packaging Details :
bearing+thin plastic film+waterproof paper+thin foam+carton/wooden cases
Model :
XI 140575N
Material :
50Mn Or according to you
Structure :
Cross roller bearing
Dimension :
462x657x45mm
Application :
Manipulators
Name :
INA Cross roller bearing slewing rings
Description

XI 140575N slewing ring bearing 462x657x45mm Cross roller XI 300713N China supplier luoyang bearingXI 180635N

  • Structure:Cross roller
  • Gear teeth: internal
  • Seals type:double seals
  • Material: 50Mn/ custom made
  • For light duty industrial manipulator or precision robotics.

Structure and Parameters:

XI 140575N slewing ring bearing 462x657x45mm Cross roller XI 300713N China supplier luoyang bearingXI 180635N

Model INA Outer dimension(mm) Mounting dimension(mm) Gear datas(mm)

Axial Static

load

rating (KN)

Weight

(KG)
Da D di H La Li n1 n2 φ1 φ2 m z do x
XIU10/288 XI120288N 216 340 38 324 252 20 20 9 9 4 56 224 340 12
XIU10/420 XI 120420N 332 486 38 462 378 16 16 14 14 4 85 340 500 24
XIU15/489 XI 160489N 384 562 45 538 440 40 40 14 14 6 66 396 710 35
XIU15/575 XI 140575N 462 657 45 625 525 16 16 18 18 6 79 474 830 45
XIU20/635 XI 180635N 504 722 54 690 580 24 24 18 18 8 65 520 1040 65
XIU30/713 XI 300713N 560 817 80 785 640 52 52 18 18 10 58 580 1980 130
XIU20/720 XI 200720N 584 812 58 780 660 40 40 18 18 8 75 600 1420 80
XIU20/865 XI 180865N 736 952 54 920 810 20 20 18 18 8 94 752 1325 90
XIU15/897 XI 140897N 776 976 54 944 850 32 32 18 18 8 99 792 1270 75
XIU30/1128 XI 301128N 936 1258 86 1210 1045 36 36 26 26 12 80 960 2825 285
XIU20/1100 XI 201100N 950 1200 70 1160 1040 30 30 22 22 10 97 970 2000 150
XIU15/1087 XI 141087N 960 1166 65 1134 1040 40 40 18 18 10 98 980 1500 105
XIU25/1120 XI 241120N 960 1228 73 1188 1052 40 40 22 22 10 98 980 2400 195
XIU20/1150 XI 221150N 984 1255 74 1215 1085 40 40 22 22 12 84 1008 2425 200
XIU25/1220 XI 261220N 1060 1330 78 1290 1150 48 48 22 22 10 108 1080 2650 230
XIU30/1304 XI 301304N 1140 1416 86 1380 1228 76 76 20 20 10 116 1160 3240 280
XIU40/1385 XI 401385N 1176 1528 110 1480 1290 56 56 26 26 12 100 1200 3450 490
XIU30/1348 XI 301348N 1180 1465 86 1425 1270 60 60 22 22 10 120 1200 3340 300
XIU30/1500 XI 301500N 1308 1630 86 1582 1418 48 48 26 26 12 111 1332 3710 380
XIU35/1615 XI 341615N 1416 1753 95 1705 1525 64 64 26 26 12 120 1440 4300 470
XIU30/1700 XI 301700N 1498 1830 92 1782 1618 56 56 26 26 14 109 1526 4250 450
XIU35/1785 XI 341785N 1568 1923 95 1875 1695 72 72 26 26 14 114 1596 4800 550
XIU40/1865 XI 401865N 1616 2024 108 1970 1760 68 68 30 30 16 103 1648 5900 750
XIU40/1945 XI 401945N 1722 2088 110 2040 1850 48 48 26 26 14 125 1750 6200 740
XIU20/1905 XI 201905N 1740 2010 82 1970 1840 48 48 22 22 12 147 1764 3450 340
XIU40/2026 XI 402026N 1764 2184 122 2130 1921 72 72 30 30 18 100 1800 6500 900
XIU45/2180 XI 452180N 1920 2355 127 2295 2065 64 64 33 33 16 122 1952 7600 1090
XIU30/2280 XI 302280N 2072 2413 110 2365 2195 84 84 26 26 14 150 2100 5900 760
XIU35/2540 XI 342540N 2286 2700 118 2640 2440 64 64 33 33 18 129 2322 6750 1040
XIU45/2600 XI 452600N 2336 2775 127 2715 2485 76 76 33 33 16 148 2368 8850 1330
XIU25/2686 XI 262686N 2480 2800 114 2760 2615 108 108 22 22 20 126 2520 5800 740
XIU40/2875 XI 402875N 2628 3040 118 2980 2775 72 72 33 33 18 148 2664 9350 1250
XIU30/2980 XI 302980N 2796 3100 109 3060 2900 160 160 22 22 12 235 2820 7200 820
XIU45/3280 XI 453280N 3006 3455 127 3395 3165 96 96 33 33 18 169 3042 11550 1710
XIU50/3383 XI 503383N 3100 3565 138 3505 3260 116 116 33 33 20 157 3140 14400 1970
XIU35/3403 XI 343403N 3168 3560 110 3500 3305 80 80 33 33 16 200 3200 9100 1290
XIU50/3500 XI 503500N 3200 3690 138 3630 3370 124 124 33 33 20 162 3240 14100 2170
XIU50/3720 XI 503720N 3420 3910 138 3850 3590 132 132 33 33 20 173 3460 15000 2310
XIU50/3820 XI 503820N 3520 4010 138 3950 3690 136 136 33 33 20 178 3560 15400 2370
XIU60/4035 XI 604035N 3720 4234 160 4174 3896 144 144 33 33 20 188 3760 17600 3100

Drawings and other parameters ,pls contact us free, thanks
