Specifications
Brand Name :
Yuhong
Model Number :
φ1500*12000mm
Certification :
CE,ISO
Place of Origin :
Henan, China
MOQ :
1set
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
15-30sets/month
Delivery Time :
10-15 working days
Packaging Details :
Standard export container, or in bulks, bare main machines, motors and small parts are packed in wooden cases. Yuhong Rotary Dryer Machine , sawdust dryer,Wood Chip Dryer
Capacity :
4-9t/h
Input moisture :
10-40%
Output moisture :
1-10%
Max feed-in temperature :
700℃
Drum diameter :
1500mm
Drum length :
12000mm
Warranty :
12months
Color :
As requirement
Description

Energy-saving hot sale in India Indonesia rotary dryer machine

Production description


Rotary dryer, also named as rotary drum dryer and rotary drying machine, is energy-saving and high efficient drying equipment. Rotary dryer is widely used for drying materials in industries like cement, mine, building materials, chemistry, food and fertilizer, etc, raw material such as: sand, coal, slag, slurry, wood chips, etc.
This rotary drying machine comes with thermocouples on the feeding and discharging device to control the temperature.Processed Materials: Manure, Sand, Coal,Slag, compound fertilizer, straw briquette fuel, granular fuel and saw dust briquette.
Applications: Industries of metallurgy, chemical engineering, construction materials and mining.
Capacity: 1-50tones per hour
Heating Fuel: Coal, Gas, Oil, Biomass fuels, Wood,etc.

Technology Parameter

Model Gradient Rotation speed Max feed-in gas temperature Power Output Weight
(%) (r/min) (℃) (kw) (t/h) (t)
600×6000 3-5 3-8 700 3 0.5-1.5 2.9
800×8000 3-5 3-8 700 4 0.8-2.0 3.5
800×10000 3-5 3-8 700 4 0.8-2.5 4.5
1000×10000 3-5 3-8 700 5.5 1.0-3.5 5.6
1200×10000 3-5 3-8 700 7.5 1.8-5 14.5
1200×12000 3-5 3-8 700 11 2-6 14.8
1500×12000 3-5 2-6 800 15 3.5-9 17.8
1800×12000 3-5 2-6 800 18 5-12 25
2200×12000 3-5 1.5-6 800 18.5 6-15 33
2200×18000 3-5 1.5-6 800 22 10-18 53.8
2200×20000 3-5 1.5-6 800 30 12-20 56
2400×20000 3-5 1.5-5 800 37 18-30 60
3000×20000 3-5 1.5-5 800 55 25-35 78
3000×25000 3-5 1.5-5 800 75 32-40 104.9

Features:

1) PLC smart control & high automaticity. The performance of rotary dryer and moisture content of dry materials is automatically controlled in stable states.
2) High heat efficiency. The design of multiple circumferential flights combination and flow rate adjustment devices ensure the control of drying period and temperature distribution. The effect of insulation is as high as 70% and raise the heat efficiency by 20%.
3) Four wheel drive, more steady and stable.
4) Save 50% space compared with traditional dryers and reduce 50% civil investment.
5) Convenient variable frequency control systems. Customer could change the material flow rate and product moisture based on their need.
6) Environmental and safe. Modular configuration of dust collection and purification systems
7) More choice for novel air furnace with high efficiency, convenient manipulation and energy control, which could reduce 30% energy cost and 20% electric cost.

Service Items:

Pre-sale
1. According to your needs, select right model for you.
2. According to your special requirements, design customized solution and manufacture customized products for you.
3. Welcome your visit.
Sale
1. Sign contract, pay deposit, we arrange production.
2. Product acceptance.
3. Help you formulate construction scheme.
After-sale
1. Assign engineer service for you on-site freely.
2. Install and adjust device, train how to operate.
3. After installation, leaving 1-2 technical staff to help you on-site production, until achieve customer satisfaction.

Packaging & Shipping

Customer Case
