5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
Specifications
Place of Origin :
Hubei, China
Brand Name :
Grandglow
Model Number :
PSM5000II
Input Voltage :
48V
Output Voltage :
110VAC/120VAC/220VAC/230VAC/240VAC
Output Current :
23A
Output Frequency :
50Hz/60Hz
Output Type :
Single
Size :
470 *275 *220MM
Type :
DC/AC Inverters
Inverter Efficiency :
90%
Certificate :
CE
Warranty :
2YEAR
Weight :
31KG
Rated Power :
5000W
Output wave form :
Pure sine wave
Peak Power :
18KW
Grid input voltage range :
160-260VAC
Battery type :
Lead acid, Gel, lithium battery, customized
AC charge function :
Can be opened or closed at any time
SCC type :
MPPT
MPPT charging efficiency :
98%
PV charging current :
Max 60A
Communication :
RS232 / WIFI / GPRS (Optional)
Packaging Details :
CARTONS
Port :
ANY PORT OF CHINA
Supply Ability :
1000 Piece/Pieces per Month
Price :
$383.00/pieces 1-49 pieces
Description

5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in

Product Description

Solar hybrid inverter, built-in MPPT solar controller.
It is suitable for all kinds of home and offiffiffice equipment,vehicle systems and solar energy systems.
Main Features
1. Digital CPU intelligent control, intelligent charging.
2. Ultra-wide AC input voltage regulation range.
3. It has the protection functions of short circuit, high and low voltage, over temperature, overload and so on.
4. Pure sine wave output, suitable for various loads.
5. Impact resistance, with super load capacity.
6. One-time soft start, triple peak power.
7. Low air consumption and high effiffifficiency.
8. Built-in AVR voltage stabilization function, continuous pure sine wave voltage stabilization output.
9. Advanced MPPT technology, high conversion effiffifficiency over 98%, to minimize energy loss.
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in
5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in

Company Information

5000W low frequency inverter 5kw 48vdc off grid inverter with MPPT controller built in

FAQ

FAQ

Q1: How to install the solar system?

A:Tell us your demand,then we will help designing it.

Q2:How about the delivery time?

A:7-30 days after payment.

Q3:What's the warranty about the products?

A:1 Year,can be extended.

Q4:Do you have any certificate?

A:Yes,we got CCC, CE,SAA,TUV,etc.You can find the detailed picture in our website.
