WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
Specifications
Place of Origin :
Hubei, China
Brand Name :
GrandGlow
Model Number :
HFM5500IIW
Input Voltage :
500VDC
Output Voltage :
230V
Output Current :
24A
Output Frequency :
50/60HZ
Output Type :
Single
Size :
115X300X440mm
Type :
DC/AC Inverters
Inverter Efficiency :
93%
Certificate :
CE
Warranty :
1 YEARS
Weight :
10kgs
Rated Power :
5500VA/5500W
Surge Power :
11000VA
Waveform :
Pure Sine Wave
Battery Voltage :
48VDC
Max AC charge current :
60A
Max PV power :
6000W
Max. solar charge current :
100A
MPPT Voltage range :
120-450VDC
Communication Interface :
USB/RS232/WiFi
Packaging Details :
cartons
Port :
SHANGHAI
Supply Ability :
1000 Piece/Pieces per Month
Price :
$126.30/cartons >=1 cartons
Description
Product Introduction

WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER


1. High efficiency pure sine wave inverter,Wide PV input range,large current intelligent 3-stage AC charging.
2. Surges to 2X continuous power for 5 seconds for motor loads.
3. Intelligent functionality enables utility and solar input prioritization.
4. Wide ulility input range.
5. Field serviceable with replacement boards and spare parts.
6. Monitor, troubleshoot, or communication with USB/RS 232.
7. System configures quickly into compact, wall-mounted system.
8. This series inverters can work without batteries when there is the sun.
Product Parameters
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
Product Details Show
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
Why Choose Us
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
WIDE PV INPUT 500VDC 5.5KW MPPT 48V 100A HYBRID OFF GRID INVERTER
Contact
Jessie Xue - Sales Manager
Grandglow New Energy Technology Co., Ltd
Mob. /Wechat: 0086-18062923557
Whatsapp: 0086-15258852509
Email: sales3@grandsolar.cn
Add.: No.278, Zhongshan Avenue, Huangjinshan Development Zone, Huangshi , China
www.grandglow.net
