22318 Series Brass / Steel / Nylon Cage Self Aligning Roller Bearing Single Row Double Row
22318 Series Brass / Steel / Nylon Cage Self Aligning Roller Bearing Single Row Double Row
22318 Series Brass / Steel / Nylon Cage Self Aligning Roller Bearing Single Row Double Row
22318 Series Brass / Steel / Nylon Cage Self Aligning Roller Bearing Single Row Double Row
22318 Series Brass / Steel / Nylon Cage Self Aligning Roller Bearing Single Row Double Row
22318 Series Brass / Steel / Nylon Cage Self Aligning Roller Bearing Single Row Double Row
Specifications
Brand Name :
Solarich
Model Number :
22318-23028CAK
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
$1.9-199
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100000/month
Delivery Time :
10-15days
Packaging Details :
Seaworthy wooden case
Type :
Roller, cylindrical, cam, ball
Number of row :
Double Row, Single Row, Four row
Precision rating :
P0 P6 P5 P4 P2, P6, P0, P4, P5
Seals type :
Open, ZZ 2RS OPEN, RS, ZZ, 2RS
Structure :
Needle roller, spherical , cylindrical , tapered
Outside diameter :
47 - 225 mm, 51.99 - 52 mm, 5 - 3000 mm, 160 - 160.01 mm, 15 - 986 mm
Material :
Chrome Steel, carbon steel/CCR 15, Gcr15, 9Cr18
Cage :
Steel Cage, e, mb, cc, nylon. Copper alloy
Service :
OEM Service.Design Service, OEM Customized Services, Customization & OEM Service, ODM, OEM
Sample :
Available
Application :
Automotive, Machinery, Taper Roller Bearing, etc, cars
Package :
Original Package, Tube&Customized, as your requests, Industrial Package
Feature :
Original Package, Original Packing, Plastic Tube + Carton +Pallet, single box or as your requirements, Industrial Packing
Quality :
P0, Good, P6, P4, P5
Product name :
1200 series single Row Double Row Brass/Steel/Nylon Cage Self-Aligning Ball Bearing
Clearance :
C3, C2, C4, C0 C2 C3 C4 C5, C0
Description

Self-aligning roller bearing

Spherical roller bearings are self-aligning roller bearings. have double row rollers, the outer ring has a shared spherical raceway, and the inner ring has two raceways that are inclined at an angle relative to the bearing axis.

They are double row, self-retaining units comprising solid outer rings with a concave raceway, inner rings with a cylindrical or tapered bore and ball and cage assemblies. This ingenious structure enables it to have self-aligning performance, so it is not easily affected by the angle between the shaft and the bearing box seat on the error or the shaft bending, and is suitable for the occasions where the installation error or the shaft deflection causes the angle error. In addition to radial loads, the bearings can also withstand axial loads acting in both directions.

22318 Series Brass / Steel / Nylon Cage Self Aligning Roller Bearing Single Row Double Row

Bearing NO. Principal dimensions Speed ratings(r/min) Basic load ratings Weight (kg)
d D B Grease Oil (kN) Dynamic (kN) Static
22318CA 90 190 64 1800 2400 483 639 8376
22318CAK 90 190 64 1800 2400 483 639 8.619
22319CA 95 200 67 1700 2200 531 705 1036
22319CAK 95 200 67 1700 2200 531 705 10.07
2232OCA 100 215 73 1400 1800 617 833 13.306
22320CAK 100 215 73 1400 1800 617 833 12.932
22322CA 110 240 80 1500 1900 7t4 968 18.252
22322CAK 110 240 80 1500 1900 714 968 17.754
22324CA 120 260 86 1300 1700 844 1157 23.042
22324CAK 120 260 86 1300 1700 844 1157 22.419
22326CA 130 280 93 1200 1600 965 IS41 28.72
22326CAK 130 280 93 1200 1600 965 1341 27.93
22328CA 140 300 102 1100 1500 1133 1614 36.203
22328CAK 140 300 102 1100 1500 1133 1614 35.182
22330CA 150 320 108 1200 1500 1271 IS48 43.923
22330CAK 150 320 108 1200 1500 1271 1848 42.679
22332CA 160 340 114 950 1300 1400 1950 51
22332CAK 160 340 114 950 1300 1400 1950 51.3
22334CA 170 S60 120 900 1200 155() 2200 56
22334CAK 170 S60 120 900 1200 1550 2200 55.8
22336CA 180 380 126 850 1100 1710 2400 72.6
22336CAK 180 380 126 850 1100 1710 2400 71.4
22338CA 190 400 132 850 1100 1870 2670 79
22338CAK 190 400 132 850 1100 1870 2670 78
22340CA 200 420 138 800 1000 2080 3000 97.9
22340CAK 200 420 138 800 1000 2080 3000 95.9
23020CA 100 150 37 1400 1800 206 325 2.36
23020CAK 100 150 37 1400 1800 206 325 2.36
23022CA 110 170 45 1400 1800 270 448 3.76
23022CAK 110 170 45 1400 1800 270 448 3.65
23024CA 120 180 46 1400 1800 295 495 4.25
23024CAK 120 180 46 1400 1800 295 495 4.12
23026CA 130 200 52 1200 1600 372 625 6.11
23026CAK 130 200 52 1200 1600 372 625 5.9
23028CA 140 210 53 1100 1500 402 6% 6.61
23028CAK 140 210 53 1100 1500 402 698 6.41

22318 Series Brass / Steel / Nylon Cage Self Aligning Roller Bearing Single Row Double Row
