Double Row Slewing Ring Bearing Large Size Turntable For Deck Crane, Wind Power
Double Row Slewing Ring Bearing Large Size Turntable For Deck Crane, Wind Power
Double Row Slewing Ring Bearing Large Size Turntable For Deck Crane, Wind Power
Double Row Slewing Ring Bearing Large Size Turntable For Deck Crane, Wind Power
Double Row Slewing Ring Bearing Large Size Turntable For Deck Crane, Wind Power
Double Row Slewing Ring Bearing Large Size Turntable For Deck Crane, Wind Power
Double Row Slewing Ring Bearing Large Size Turntable For Deck Crane, Wind Power
Double Row Slewing Ring Bearing Large Size Turntable For Deck Crane, Wind Power
Double Row Slewing Ring Bearing Large Size Turntable For Deck Crane, Wind Power
Double Row Slewing Ring Bearing Large Size Turntable For Deck Crane, Wind Power
Specifications
Brand Name :
Solarich
Model Number :
031.25.260---032.60.4000
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
$99-199
Payment Terms :
D/A, L/C, T/T, Western Union
Supply Ability :
100000/month
Delivery Time :
15-25days
Packaging Details :
Seaworthy wooden case
Type :
Double row ball slewing bearing with same diameter
Precision rating :
P0 P6 P5 P4 P2, P6, P0, P4, P5
Material :
42CrMo, 50Mn , chrome Steel, carbon steel/CCR 15, Gcr15, 9Cr18
Feature :
Long Life, durable
Application :
Automotive, Machinery, Taper Roller Bearing, etc, cars
Lubricating :
EP2 grease or customized
Customized :
Available
Service :
OEM Service.Design Service, OEM Customized Services, Customization & OEM Service, ODM, OEM
Packing :
Industrial packing, Single Box, Box Packing+Carton+Pallets
Specification :
Customized
Description

Double row ball slewing bearing

The double row ball slewing bearing has three seat rings , the steel ball and the spaces can be directly arranged into the upper and lower races. Two rows of steel balls are fitted according to the force born . Open mode fitting is extraordinary convenient .The load angles of both upper and lower race are 90°,which enable to bear large axial force and the tilting moment.

As the axial and radial dimension of the double row ball slewing bearing are rather large , structural is tightening and can support high static loads. They are mainly used in situations with variational load position and direction and continuously rotating . Especially suitable for tower cranes which require working radius over medium range , mobile crane and loading and unloading machinery .

Designations Gear parameters External gear parameters Internal gear parameters Weight (kg)
External gear Internal gear b m da Z da Z
031.25.560 033.25.560 60 5 704 138 417 84 156
032.25.560 034.25.560 60 6 706.8 115 410.4 69
031.25.630 033.25.630 60 6 790.8 129 482.4 81 175
032.25.630 034.25.630 60 8 790.4 96 475.2 60
031.25.710 033.25.710 60 6 862.8 141 560.4 94 198
032.25.710 034.25.710 60 8 862.4 105 555.2 70
031.30.800 033.30.800 80 8 982.4 120 619.2 78 324
032.30.900 034.30.900 80 10 1088 106 714 72
031.30.1000 033.30.1000 80 10 1198 117 814 82 405
032.30.1000 034.30.1000 80 12 1197.6 97 796.8 67
031.30.1120 033.30.1120 80 10 1318 129 924 93 455
032.30.1120 034.30.1120 80 12 1317.6 107 916.8 77
031.40.1250 033.40.1250 90 12 1497.6 122 1012.8 85 837
032.40.1250 034.40.1250 90 14 1495.2 104 1013.6 73
031.40.1400 033.40.1400 90 12 1641.6 134 1156.8 97 940
032.40.1400 034.40.1400 90 14 1649.2 115 1153.6 83
031.40.1600 033.40.1600 90 14 1845.2 129 1349.6 97 1075
032.40.1600 034.40.1600 90 16 1852.8 113 1350.4 85
031.40.1800 033.40.1800 90 14 2055.2 144 1545.6 111 1213
032.40.1800 034.40.1800 90 16 2060.8 126 1542.4 97
031.50.200 033.50.2000 120 16 2300.8 141 1702.4 107 1921
032.50.2000 034.50.2000 120 18 2300.4 125 1699.32 95
031.50.2240 033.50.2240 120 16 2540.8 156 1942.4 122 2159
032.50.2240 034.50.2240 120 18 2552.4 139 1933.2 108
031.50.2500 033.50.2500 120 18 2804.4 153 2203.2 123 2406
032.50.2500 034.50.2500 120 20 2816 138 2188 110
031.50.2800 033.50.2800 120 18 3110.4 170 2491.2 139 3221
032.50.2800 034.50.2800 120 20 3116 153 2488 125
031.60.3150 033.60.3150 150 20 3536 174 2768 139 4652
032.60.3150 034.60.3150 150 22 3537.6 158 2758.8 126
031.60.3550 033.60.3550 150 20 3936 194 3168 159 5262
032.60.3550 034.60.3550 150 22 3933.6 176 3176.8 145
031.60.4000 033.60.4000 150 22 4395.6 197 3616.8 165 5938
032.60.4000 034.60.4000 150 25 4395 173 3610 145
