Double Row Different Diameter Large Size Slewing Ring Bearing For Deck Crane, Wind Power
Double Row Different Diameter Large Size Slewing Ring Bearing For Deck Crane, Wind Power
Double Row Different Diameter Large Size Slewing Ring Bearing For Deck Crane, Wind Power
Double Row Different Diameter Large Size Slewing Ring Bearing For Deck Crane, Wind Power
Double Row Different Diameter Large Size Slewing Ring Bearing For Deck Crane, Wind Power
Double Row Different Diameter Large Size Slewing Ring Bearing For Deck Crane, Wind Power
Double Row Different Diameter Large Size Slewing Ring Bearing For Deck Crane, Wind Power
Double Row Different Diameter Large Size Slewing Ring Bearing For Deck Crane, Wind Power
Specifications
Brand Name :
Solarich
Model Number :
020.25.500---020.60.4500
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
$99-199
Payment Terms :
D/A, L/C, T/T, Western Union
Supply Ability :
100000/month
Delivery Time :
15-25days
Packaging Details :
Seaworthy wooden case
Type :
Double row ball slewing bearing with different diameter
Precision rating :
P0 P6 P5 P4 P2, P6, P0, P4, P5
Material :
42CrMo, 50Mn , chrome Steel, carbon steel/CCR 15, Gcr15, 9Cr18
Feature :
Long Life, durable
Application :
Automotive, Machinery, Taper Roller Bearing, etc, cars
Lubricating :
EP2 grease or customized
Customized :
Available
Service :
OEM Service.Design Service, OEM Customized Services, Customization & OEM Service, ODM, OEM
Packing :
Industrial packing, Single Box, Box Packing+Carton+Pallets
Specification :
Customized
Description

Double row ball slewing bearing

The double row ball slewing bearing has three seat rings , the steel ball and the spaces can be directly arranged into the upper and lower races. Two rows of steel balls are fitted according to the force born . Open mode fitting is extraordinary convenient .The load angles of both upper and lower race are 90°,which enable to bear large axial force and the tilting moment.

As the axial and radial dimension of the double row ball slewing bearing are rather large , structural is tightening and can support high static loads. They are mainly used in situations with variational load position and direction and continuously rotating . Especially suitable for tower cranes which require working radius over medium range , mobile crane and loading and unloading machinery .

Model Boundary dimensions(mm) Bolt hole diameter(mm) Gear parameters(mm) Weight
Non-gear External gear Internal gear D d H D1 D2 n m Da Z da Z b X kg
020-25-500 021-25-500 023-25-500 616 384 106 580 420 20 5 645 126 355 72 60 0.5 100
022-25-500 024-25-500 616 384 106 580 420 20 6 648 105 348 59 60 0.5 100
020-25-560 021-25-560 023-25-560 676 444 106 640 480 20 5 705 138 415 84 60 0.5 115
022-25-560 024-25-560 676 444 106 640 480 20 6 708 115 408 69 60 0.5 115
020-25-630 021-25-630 023-25-630 746 514 106 710 550 24 6 792 129 480 81 60 0.5 130
022-25-630 024-25-630 746 514 106 710 550 24 8 792 96 472 60 60 0.5 130
020-25-710 021-25-710 023-25-710 826 594 106 790 630 24 6 864 141 558 94 60 0.5 140
022-25-710 024-25-710 826 594 106 790 630 24 8 864 105 552 70 60 0.5 140
020-30-800 021-30-800 023-30-800 942 658 124 898 702 30 8 984 120 616 78 80 0.5 200
022-30-800 024-30-800 942 658 124 898 702 30 10 990 96 610 62 80 0.5 200
020-30-900 021-30-900 023-30-900 1042 758 124 998 802 30 8 1088 133 712 90 80 0.5 250
022-30-900 024-30-900 1042 758 124 998 802 30 10 1090 106 710 72 80 0.5 250
020-30-1000 021-30-1000 023-30-1000 1142 858 124 1098 902 36 10 1200 117 810 82 80 0.5 300
022-30-1000 024-30-1000 1142 858 124 1098 902 36 12 1200 97 792 67 80 0.5 300
020-30-1120 021-30-1120 023-30-1120 1262 978 124 1218 1022 36 10 1320 129 920 93 80 0.5 340
022-30-1120 024-30-1120 1262 978 124 1218 1022 36 12 1320 107 912 77 80 0.5 340
020-40-1250 021-40-1250 023-40-1250 1426 1074 160 1374 1126 40 12 1500 122 1008 85 90 0.5 580
022-40-1250 024-40-1250 1426 1074 160 1374 1126 40 14 1498 104 1008 73 90 0.5 580
020-40-1400 021-40-1400 023-40-1400 1576 1224 160 1524 1272 40 12 1644 134 1152 97 90 0.5 650
022-40-1400 024-40-1400 1576 1224 160 1524 1272 40 14 1652 115 1148 83 90 0.5 650
020-40-1600 021-40-1600 023-40-1600 1776 1424 160 1724 1476 45 14 1848 129 1344 97 90 0.5 750
022-40-1600 024-40-1600 1776 1424 160 1724 1476 45 16 1856 113 1344 85 90 0.5 750
020-40-1800 021-40-1800 023-40-1800 1976 1624 160 1924 1676 45 14 2058 144 1540 111 90 0.5 820
022-40-1800 024-40-1800 1976 1624 160 1924 1676 45 16 2064 126 1536 97 90 0.5 820
020-50-2000 021-50-2000 023-50-2000 2215 1785 190 2149 1851 48 16 2304 141 1696 107 120 0.5 1150
022-50-2000 024-50-2000 2215 1785 190 2149 1851 48 18 2304 125 1692 95 120 0.5 1150
020-50-2240 021-50-2240 023-50-2240 2455 2025 190 2389 2091 48 16 2544 156 1936 122 120 0.5 1500
022-50-2240 024-50-2240 2455 2025 190 2389 2091 48 18 2556 139 1926 108 120 0.5 1500
020-50-2500 021-50-2500 023-50-2500 2715 2285 190 2649 2351 56 18 2804 153 2196 123 120 0.5 1500
022-50-2500 024-50-2500 2715 2285 190 2649 2351 56 20 2820 138 2180 110 120 0.5 1500
020-50-2800 021-50-2800 023-50-2800 3015 2585 190 2949 2651 56 18 3114 170 2484 139 120 0.5 1900
022-50-2800 024-50-2800 3015 2585 190 2949 2651 56 20 3120 153 2480 125 120 0.5 1900
020-60-3150 021-60-3150 023-60-3150 3428 2872 226 3338 2962 56 20 3540 174 2760 139 150 0.5 3300
022-60-3150 024-60-3150 3428 2872 226 3338 2962 56 22 3542 158 2750 126 150 0.5 3300
020-60-3550 021-60-3550 023-60-3550 3828 3272 226 3738 3362 56 20 3940 194 3160 159 150 0.5 3700
022-60-3550 024-60-3550 3828 3272 226 3738 3362 56 22 3938 176 3168 145 150 0.5 3700
020-60-4000 021-60-4000 023-60-4000 4278 3722 226 4188 3812 60 22 4400 197 3608 165 150 0.5 4200
022-60-4000 024-60-4000 4278 3722 226 4188 3812 60 25 4400 173 3600 145 150 0.5 4200
020-60-4500 021-60-4500 023-60-4500 4778 4222 226 4688 4312 60 22 4884 219 4114 188 150 0.5 4700
022-60-4500 024-60-4500 4778 4222 226 4688 4312 60 25 4900 193 4100 165 150 0.5 4700

Double Row Different Diameter Large Size Slewing Ring Bearing For Deck Crane, Wind Power
