Specifications
Brand Name :
Solarich
Model Number :
31330XJ2, 31320XJ2/CL7CVQ051, 31316J1/QCL7C
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
Customized
Payment Terms :
L/C, T/T, D/P, Western Union
Supply Ability :
1000000
Delivery Time :
10-15days
Packaging Details :
Original Package, Tube&Customized, as your requests, Industrial Package
Number of row :
single row , double row , four row
Precision rating :
P0 P6 P5 P4 P2, P6, P0, P4, P5
Type :
roller
Structure :
Taper
Seals type :
Open, ZZ 2RS OPEN, RS, ZZ, 2RS
Material :
Chrome Steel, bearing steel, stainless steel, AISI440C, Gcr15
Service :
OEM Service.Design Service, OEM Customized Services, Customization & OEM Service, ODM, OEM
Application :
Automotive, Machinery, Taper Roller Bearing, etc, cars
Cage :
Steel Cage, e, mb, cc, nylon. Copper alloy
Outside diameter :
47 - 225 mm, 51.99 - 52 mm, 5 - 3000 mm, 160 - 160.01 mm, 15 - 986 mm
Clearance :
C3, C4, C2, CO, C1 C2 0 C3 C4 C5
Vibration :
V1 V2 V3 V4, Z1V1 Z2V2 Z3V3 Z4V4
Feature :
Long Life, durable, 2.9921x5.1969x1.5354"
Package :
Original Package, Tube&Customized, as your requests, Industrial Package
Stock :
50000pcs, Ready Goods, 200 pieces, large, Inch Bearing
Description

Tapered roller bearing

Tapered roller bearing refers to radial thrust type rolling bearing with tapered roller rolling body. There are two kinds of small cone Angle and large cone Angle. Small cone Angle mainly bear radial load mainly radial and axial combined load, often in double use, reverse installation, inner and outer seat ring can be installed separately, radial and axial clearance can be adjusted during installation and use; The large cone Angle is mainly used to bear the combined axial and radial loads mainly based on axial loads. It is generally not used to bear pure axial loads alone, but can be used to bear pure radial loads when it is configured (the same end is installed relatively).

Tapered roller bearings belong to separation bearings, bearing inner and outer rings have tapered raceway. The bearings can be divided into single row, double row and four row tapered roller bearings according to the number of roller rows. Single row tapered roller bearings can withstand radial load and single direction axial load. When the bearing bears radial load, there will be an axial component, so when another bearing that can withstand the axial force in the opposite direction is needed to balance it.

The structure, assembly dimension accuracy and rotation accuracy of inch tapered roller bearings are different from those of metric bearings .It is mainly used for imported machinery or industries with special needs.

The inch tapered roller bearing refers to the tapered roller bearing whose overall dimensions are measured in inches , originated from Britain and the United States.

31330XJ2 Metric Tapered Roller Bearing Single Row , Double Row , Four Row31330XJ2 Metric Tapered Roller Bearing Single Row , Double Row , Four Row31330XJ2 Metric Tapered Roller Bearing Single Row , Double Row , Four Row31330XJ2 Metric Tapered Roller Bearing Single Row , Double Row , Four Row

Bearing No. Dimensions (mm) Basic Load Rating (KN) Pu Rotation Speed (中庁) Weight (Kg)
di D B Cr Cor Speed Grade Speed Limit
31330XJ2 150 320 82 781 1020 100 1400 2000 29.5
31328XJ2 140 300 77 693 900 88 1500 2200 24.5
31326XJ2 130 280 72 605 780 81.5 1600 2400 18.5
31324XJ2 120 260 68 539 695 73.5 1700 2400 15.5
31322XJ2 110 240 63 457 585 62 1900 2800 12.0
31320XJ2/CL7CVQ051 100 215 56.5 430 465 51 2400 3000 8.60
31319J2 95 200 49.5 292 355 39 2400 3400 6.95
31318J2 90 190 46.5 264 315 36.5 2400 3400 5.90
31317J2 85 180 44.5 242 285 33.5 2600 3800 4.60
31316J1/QCL7C 80 170 42.5 260 265 32 3000 4000 4.05
31315J2/QCL7C 75 160 40 240 245 29 3200 4300 3.50
31314J2/QCL7C 70 150 38 216 220 27 3400 4500 2.95
31313J2/QCL7C 65 140 36 190 193 23.6 3600 4800 2.35
31312J2/QCL7C 60 130 33.5 166 166 20.4 3800 5300 1.90
31311J2/QCL7C 55 120 31.5 140 137 16.6 4300 5600 1.55
31310J2/QCL7C 50 110 29.25 122 120 14.3 4500 6000 1.20
31309J2/QCL7C 45 100 27.25 106 102 12.5 5000 6700 0.95
31308J2/QCL7C 40 90 25.25 85 81.5 9.5 5600 7500 0.72
31307J2/Q 35 80 22.75 71 67 7.8 6300 8500 0.52
31306J2/Q 30 72 20.75 55 50 5.7 7500 9500 0.39
31305J2 25 62 18.25 38 40 4.4 7500 11000 0.26
