Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
Specifications
Brand Name :
Solarich
Model Number :
33205/Q,, 33208/QCL7C, 33213TN9/Q
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
Customized
Payment Terms :
L/C, T/T, D/P, Western Union
Supply Ability :
1000000
Delivery Time :
10-15days
Packaging Details :
Original Package, Tube&Customized, as your requests, Industrial Package
Number of row :
single row , double row , four row
Precision rating :
P0 P6 P5 P4 P2, P6, P0, P4, P5
Type :
roller
Structure :
Taper
Seals type :
Open, ZZ 2RS OPEN, RS, ZZ, 2RS
Material :
Chrome Steel, bearing steel, stainless steel, AISI440C, Gcr15
Service :
OEM Service.Design Service, OEM Customized Services, Customization & OEM Service, ODM, OEM
Application :
Automotive, Machinery, Taper Roller Bearing, etc, cars
Cage :
Steel Cage, e, mb, cc, nylon. Copper alloy
Outside diameter :
47 - 225 mm, 51.99 - 52 mm, 5 - 3000 mm, 160 - 160.01 mm, 15 - 986 mm
Clearance :
C3, C4, C2, CO, C1 C2 0 C3 C4 C5
Vibration :
V1 V2 V3 V4, Z1V1 Z2V2 Z3V3 Z4V4
Feature :
Long Life, durable, 2.9921x5.1969x1.5354"
Package :
Original Package, Tube&Customized, as your requests, Industrial Package
Stock :
50000pcs, Ready Goods, 200 pieces, large, Inch Bearing
Description

Tapered roller bearing

Tapered roller bearing refers to radial thrust type rolling bearing with tapered roller rolling body. There are two kinds of small cone Angle and large cone Angle. Small cone Angle mainly bear radial load mainly radial and axial combined load, often in double use, reverse installation, inner and outer seat ring can be installed separately, radial and axial clearance can be adjusted during installation and use; The large cone Angle is mainly used to bear the combined axial and radial loads mainly based on axial loads. It is generally not used to bear pure axial loads alone, but can be used to bear pure radial loads when it is configured (the same end is installed relatively).

Tapered roller bearings belong to separation bearings, bearing inner and outer rings have tapered raceway. The bearings can be divided into single row, double row and four row tapered roller bearings according to the number of roller rows. Single row tapered roller bearings can withstand radial load and single direction axial load. When the bearing bears radial load, there will be an axial component, so when another bearing that can withstand the axial force in the opposite direction is needed to balance it.

The structure, assembly dimension accuracy and rotation accuracy of inch tapered roller bearings are different from those of metric bearings .It is mainly used for imported machinery or industries with special needs.

The inch tapered roller bearing refers to the tapered roller bearing whose overall dimensions are measured in inches , originated from Britain and the United States.

Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four RowDurable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four RowDurable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four RowDurable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row

Bearing No. Dimensions (mm) Basic Load Rating (KN) Pu Rotation Speed (rpm) Weight (Kg)
di D B Cr Cor Speed Grade Speed Limit
33205/Q 25 52 22 54 56 6 10000 13000 0.23
30332J2 160 340 75 913 1180 114 1500 2000 29.0
33220 100 180 63 429 655 71 2400 3600 6.95
33219 95 170 58 374 560 62 2600 3800 5.50
33217/Q 85 150 49 286 430 48 3000 4300 3.70
33216/Q 80 140 46 251 375 41.5 3200 4500 2.90
33215/Q 75 130 41 209 300 34 3400 4800 2.25
33214/Q 70 125 41 201 285 32.5 3600 5000 2.10
33213TN9/Q 65 120 41 194 270 30.5 3800 5300 2.05
33213/Q 65 120 41 194 270 30.5 3800 5300 2.05
33212/Q 60 110 38 168 236 26.5 4000 6000 1.60
33211/Q 55 100 35 138 190 21.6 4500 6300 1.20
33210/Q 50 90 32 114 160 18.3 5000 7000 0.90
33209/Q 45 85 32 108 143 16.3 5300 7500 0.82
33208/QCL7C 40 80 32 120 132 15 6300 8500 0.77
33206/Q 30 62 25 75 76.5 8.5 8500 11000 0.37

Durable Metric Tapered Roller Bearing 33205/Q Single Row, Double Row / Four Row
