Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Specifications
Brand Name :
Solarich
Model Number :
RNA 49..RS, RNA 49..2RS
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
$1.9-199
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100000/month
Delivery Time :
10-15days
Packaging Details :
Seaworthy wooden case
Type :
Needle bearing with single seal & double seal
Structure :
Needle roller
Service :
OEM Service.Design Service, OEM Customized Services, Customization & OEM Service, ODM, OEM
Application :
Automotive, Machinery, Taper Roller Bearing, etc, cars
Cage :
Steel Cage, e, mb, cc, nylon. Copper alloy
Feature :
Long Life, durable
Package :
Original Package, Tube&Customized, as your requests, Industrial Package
Seals type :
Open, ZZ 2RS OPEN, RS, ZZ, 2RS
Precision rating :
P0 P6 P5 P4 P2, P6, P0, P4, P5
Outside diameter :
47 - 225 mm, 51.99 - 52 mm, 5 - 3000 mm, 160 - 160.01 mm, 15 - 986 mm
Description

Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner RingNeedle bearing
Needle bearing is a cylindrical roller bearing, relative to its diameter, the roller is both thin and long this roller called needle although has a smaller section, bearing still has a higher load bearing capacity, needle bearing is equipped with thin and long roller (roller diameter D 5mm,L/D 2.5,L is the length of roller), so the radial structure is compact, and its inner diameter size and load capacity are the same as other types of bearings, while the outer diameter is the smallest, especially suitable for the radial installation size of the support structure is limited .

Shaft DiameterBearing No.Boundary DimensionsBasic Load RatingsLimiting Speed
RNA 49..RSRNA 49..2RSFwDCr(s)CCoOil
mmsingle sealeddouble sealed mm min.Nrpm
14RNA 4900 RSRNA 4900.2RS1422130.36800690013000
16RNA 4901 RSRNA 4901.2RS1624130.37600830012000
20RNA 4902 RSRNA 4902.2RS2028130.386001030010000
22RNA 4903 RSRNA 4903.2RS2230130.38800110009000
25RNA 4904 RSRNA 4904.2RS2537170.317300199007500
30RNA 4905 RSRNA 4905.2RS3042170.319300242006500
35RNA 4906 RSRNA 4906.2RS3547170.321100285005500
42RNA 4907 RSRNA 4907.2RS4255200.626500395004800
48RNA 4908 RSRNA 4908.2RS4862220.636000530004200
52RNA 4909 RSRNA 4909.2RS5268220.638000590003900
58RNA 4910 RSRNA 4910.2RS5872220.640000640003500


Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner RingSealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
Sealed Needle Roller Bearings Higher Load Carrying Capacity Without Inner Ring
