Professional 6200 Series Ball Bearing Deep Groove With Long Service Life
Professional 6200 Series Ball Bearing Deep Groove With Long Service Life
Professional 6200 Series Ball Bearing Deep Groove With Long Service Life
Professional 6200 Series Ball Bearing Deep Groove With Long Service Life
Professional 6200 Series Ball Bearing Deep Groove With Long Service Life
Professional 6200 Series Ball Bearing Deep Groove With Long Service Life
Professional 6200 Series Ball Bearing Deep Groove With Long Service Life
Professional 6200 Series Ball Bearing Deep Groove With Long Service Life
Professional 6200 Series Ball Bearing Deep Groove With Long Service Life
Professional 6200 Series Ball Bearing Deep Groove With Long Service Life
Specifications
Description

6200 series

Deep groove ball bearing formerly known as single row centripetal ball bearing, is the most widely used kind of rolling bearing.

Send Email Call Us
AddThis Sharing Buttons
Share to FacebookFacebookShare to TwitterTwitterShare to LinkedInLinkedInShare to PinterestPinterestShare to ...AddThis
Introduction Industry Video Send Message

Introduction

Deep groove ball bearing formerly known as single row centripetal ball bearing, is the most widely used kind of rolling bearing. Its characteristics are small friction resistance, high speed, can be used to bear radial load or radial and axial combined load on the parts, can also be used to bear axial load on the parts, When it only bears radial load, the contact Angle is zero.

When deep groove ball bearings have large radial clearance, they have the performance of angular contact bearings and can withstand large axial loads. The friction coefficient of deep groove ball bearings is very small, and the ultimate speed is also very high.

PRODUCT SPECIFICATION

Bearing No. Dimensions (mm) Basic Load Rating (kN) Limit Speed (rpm) Weight (Kg)
d D B rs min Grease Oil
Cr Cor
6200 10 30 9 0.6 5.1 2.39 25000 30000 0.032
6201 12 32 10 0.6 6.1 2.75 22000 26000 0.037
6202 15 35 11 0.6 7.75 3.6 19000 23000 0.045
6203 17 40 12 0.6 9.6 4.6 18000 21000 0.066
6204 20 47 14 1 12.8 6.65 16000 18000 0.106
6205 25 52 15 1 14 7.85 13000 15000 0.128
6206 30 62 16 1 19.5 11.3 11000 13000 0.199
6207 35 72 17 1.1 25.7 15.3 9800 11000 0.288
6208 40 80 18 1.1 29.1 17.8 8700 10000 0.366
6209 45 85 19 1.1 32.5 20.4 7800 9200 0.398
6210 50 90 20 1.1 35 23.2 7100 8300 0.454
6211 55 100 21 1.5 43.5 29.2 6400 7600 0.601
6212 60 110 22 1.5 52.5 36 6000 7000 0.783
6213 65 120 23 1.5 57.5 40 5500 6500 0.99
6214 70 125 24 1.5 62 44 5100 6000 1.07
6215 75 130 25 1.5 66 49.5 4800 5600 1.18
6216 80 140 26 2 72.5 53 4500 5300 1.4
6217 85 150 28 2 83.5 64 4200 5000 1.79
6218 90 160 30 2 96 71.5 4000 4700 2.15
6219 95 170 32 2.1 109 82 3700 4400 2.62
6220 100 180 34 2.1 122 93 3500 4200 3.14
6221 105 190 3
