Specifications
Description

6900 Series

Deep groove ball bearing formerly known as single row centripetal ball bearing, is the most widely used kind of rolling bearing.

Send Email Call Us
AddThis Sharing Buttons
Share to FacebookFacebookShare to TwitterTwitterShare to LinkedInLinkedInShare to PinterestPinterestShare to ...AddThis
Introduction Industry Video Send Message

Introduction

Deep groove ball bearing formerly known as single row centripetal ball bearing, is the most widely used kind of rolling bearing. Its characteristics are small friction resistance, high speed, can be used to bear radial load or radial and axial combined load on the parts, can also be used to bear axial load on the parts, When it only bears radial load, the contact Angle is zero.

When deep groove ball bearings have large radial clearance, they have the performance of angular contact bearings and can withstand large axial loads. The friction coefficient of deep groove ball bearings is very small, and the ultimate speed is also very high.

PRODUCT SPECIFICATION

Bearing No. Dimensions (mm) Basic Load Rating (kN) Limit Speed (rpm) Weight (Kg)
d D B rs min Grease Oil
Cr Cor
6900 10 22 6 0.3 2.7 1.27 30000 36000 0.009
6901 12 24 6 0.3 2.89 1.46 27000 32000 0.011
6902 15 28 7 0.3 3.65 2 24000 28000 0.016
6903 17 30 7 0.3 4.65 2.58 22000 26000 0.018
6904 20 37 9 0.3 6.4 3.7 19000 23000 0.036
6905 25 42 9 0.3 7.05 4.55 16000 19000 0.042
6906 30 47 9 0.3 7.25 5 14000 17000 0.048
6907 35 55 10 0.6 9.55 6.85 12000 15000 0.074
6908 40 62 12 0.6 12.2 8.9 11000 13000 0.11
6909 45 68 12 0.6 13.1 10.4 9000 12000 0.128
6910 50 72 12 0.6 13.4 11.2 8900 11000 0.132
6911 55 80 13 1 16 13.3 8200 9600 0.18
6912 60 85 13 1 16.4 14.3 7600 8900 0.193
6913 65 90 13 1 17.4 16.1 7000 8200 0.206
6914 70 100 16 1 23.7 21.2 6500 7700 0.334
6915 75 105 16 1 24.4 22.6 6100 7200 0.353
6916 80 110 16 1 24.9 24 5700 6700 0.373
6917 85 120 18 1.1 32 29.6 5400 6300 0
