55kw Pump Soft Starters Built In Bypass Electronic Starter For Three Phase Motor
55kw Pump Soft Starters Built In Bypass Electronic Starter For Three Phase Motor
55kw Pump Soft Starters Built In Bypass Electronic Starter For Three Phase Motor
55kw Pump Soft Starters Built In Bypass Electronic Starter For Three Phase Motor
Specifications
Brand Name :
EMHEATER
Model Number :
EM-GB3-055
Certification :
CE, Rohs,ISO9001
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T, Western Union
Supply Ability :
1000pcs per week
Delivery Time :
1~7 work days
Output Type :
TRIPLE
Output Voltage :
380V
Output Frequency :
50/60Hz
Description

55kw 3phase 400V built in bypass soft starter for pump

EM Motor Soft Starter

This soft starter is an advanced digital soft starter solution for motors from 11kW to 600kW. Provides a complete range of motor and system protection features to ensure reliable performance even in the toughest installation environments.

Selectable soft starting profiles Customisable protection

Adaptive Control

Constant Current

Current Ramp

Motor overload

Excess Start Time

Undercurrent

Instantaneous overcurrent

Current imbalance

Mains frequency

Input Trip

Motor thermistor

Power circuit

Phase sequence
Selectable soft stopping profiles Models for all connection requirements

Coast To Stop

Timed voltage ramp soft stop

Adaptive Control

Brake

23 A~1000 A (nominal)

380~415 VAC

Internally bypassed

In-line or inside delta connection
Extensive input and output options Optional features for advanced applications

Remote control inputs (3 fixed, 2 programmable

Relay outputs (1 fixed, 3 programmable)

Analog output

Built-in PT100 RTD input

Optional expansion cards

Input/output expansion

RTD and Ground fault protection

Communication modules: Modbus, Modbus RTU
Easy-to-read display with comprehensive feedback

Removable keypad

Multi-language feedback

Date and time stamped event logging

Operational counters (number of starts, hours-run, kWh)

Performance monitoring (current, voltage, power factor, kWh)

User-programmable monitoring screen

Model

Rated Power

Rated Current

Dimensions(mm)

N.W.

(KW)

(A)

A

B

C

D

E

(Kg)
EM-GB-011 11 22 152 92 312 269 215 5.2
EM-GB-015 15 30
EM-GB-018 18.5 37
EM-GB-022 22 44
EM-GB-030 30 60
EM-GB-037 37 75 152 92 312 269 215 5.2
EM-GB-045 45 90
EM-GB-055 55 110
EM-GB-075 75 150 275 160 410 390 265 18.3
EM-GB-090 90 180
EM-GB-115 115 230
EM-GB-132 132 264 443

320

160*2

 600 540 290 35.8
EM-GB-160 160 320
EM-GB-200 200 400
EM-GB-250 250 500
EM-GB-280 280 560
EM-GB-315 315 630
EM-GB-355 355 710

55kw Pump Soft Starters Built In Bypass Electronic Starter For Three Phase Motor

55kw Pump Soft Starters Built In Bypass Electronic Starter For Three Phase Motor

55kw Pump Soft Starters Built In Bypass Electronic Starter For Three Phase Motor

55kw Pump Soft Starters Built In Bypass Electronic Starter For Three Phase Motor
