22A 15HP Solar Pump Inverters DC To AC Motor Drive
22A 15HP Solar Pump Inverters DC To AC Motor Drive
22A 15HP Solar Pump Inverters DC To AC Motor Drive
22A 15HP Solar Pump Inverters DC To AC Motor Drive
Specifications
Brand Name :
EMHEATER
Model Number :
EM15-SP3-011
Certification :
CE,Rohs,3C
Place of Origin :
CHINA
MOQ :
1
Price :
Please contact quotation
Payment Terms :
T/T, Western Union
Supply Ability :
1000 units per week
Delivery Time :
3-8 work days
Packaging Details :
Standard packing
Products Name :
Solar Pump Inverters
Rated Power :
15HP
Input Voltage :
350V~750V
Output Voltage :
3 PHASE 0~380V
Type :
DC to AC
Output Current :
22A
Output Frequency :
0~600Hz
Color :
Black
Description

15HP Solar Pump Inverters ac to ac DC 250V to DC 750V ac motor drive

EM15-SP series solar inverter is high-efficiency solar water pump controller, which with high MPPT efficiency, green environmental protection, economic and energy saving, widely use for agricultural irrigation, water supply system and etc.

Products Feature:

Energy consumption
Energy Consumption Comparison :Use the traditional energy will cause pollution,and in the cost of rising trend,the use of clean energy has use cost and environmental cost advantages.

Maintenance costs
Use and maintenance:The solar energy system life for up to 25 years,and low failure rate , Automatic operation ,
Don't need someone to watch,Maintenance personnel can be divided into many groups to patrol.

  • The water level detection functions, which can support terminal /analog detection.
  • PV power, PV current, pump flow rate and other operating parameters are accurately displayed.
  • All series of products can realize the switching of AC power supply or PV power supply to meet the 24-hour work;
  • Accurate and fast MPPT algorithm tracking PV battery maximum power point, ensure 99% solar power tracking efficiency.
  • Support for basic function of inverters, such as terminal control start and stop, RS485 communication, which can remote operation and monitoring.

EM15-SP3

Description

d751d52d20045d57d5011015018022030037045
055075090110132160200220250280315355400
DC input (+, -)
Rated power/KW0.751.52.245.57.5111518.522303745
557590110132160200220250280315355400
Min. DC voltage/V280
Max.DC voltage/V750
Recommended MPPT range /V350~750
AC output(U, V, W)
Output current2.13.85.19131725323745607591
112150176210253304377426465520585650725
Output frequency0~50/60Hz
Power factor>0.99
Communication modeRS485 communication
Protection classIP20
Ambient temperature-10℃~ +40℃(ambient temperation at 40℃~50℃,please keep derated use)
Storage temperature-20℃~ +60℃
HumiditySmaller than 95%RH, non-condensation
CoolingForced Air cooling
AltitudeLower than 1000 m
HumidityLess than 95%RH, without condensing
VibrationLess than 5.9 m/s2 (0.6 g)
