Sinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 Cabin
Sinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 Cabin
Sinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 Cabin
Sinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 Cabin
Sinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 Cabin
Sinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 Cabin
Sinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 Cabin
Sinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 Cabin
Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
1000units/month
Delivery Time :
Within 35 days
Packaging Details :
nude
color :
yellow
material :
Q345
drive hand :
lhd or rhd
emission stander :
Euro2 ,3
condition :
new
Drive wheel :
6x4
Fuel type :
Diesel
Capacity (load) :
31 - 40t
Emission standard :
Euro 3
Description

Sinotruk howo7 dump truck 6x4 30-40T 16m3 capacity hw76 cabin

1. About our howo dump trucks :The main product we have is tipper trucks, tractor trucks, conceret mixers,cargo trucks, dry cement transport truck,fire fighting truck ,all-wheel driving wheel ,oil/water/fuel tanker truck,mining dump truck,port terminal tractor truck ,semi-trailer truck head , special trucks for army and so on.

2. About CNHTC howo dump truck : Be comprehensive with Euro2 and Euro3 engine equipped. Driving type: 4×2, 4×4 6×2, 6×6 ,6×4, 8×4 and 10×4 etc. Power range:

266PS -420PS.howo Leader In Heavy Duty Truck Industry Driving King On The Road New HOWO dump truck, High Quality , More Lighter 1.High Level Comfortable:Cabin 4

point full -floating air suspension ,adjustable steering wheel with various heightsand angles.air suspension

3.High Security :The key parts adopt the world's top products

4.Top configration :Discal brakes +EVB,ABS+ASR+EBL+TPM,More Powerful electronic management system. 4.High Quality :CNHTC's base on Strong technical support

and top level technology

DESCRIPTION & SPECIFICATIONS
Item HOWO 6×4 dump truck
Model zz3257n3847A
Gross Weight 25000kg
Overrall Dimensions 8545×2496×3360(mm)
Engine WD615.47, 371HP, 273kw/2200rpm, EURO II Emission, 9726cc capacity
Turbo-charging, inter-cooling, 6 cylinder in line
Emission standard EURO II
Transmission HW19710,10forward&2reverse,HOWO brand
Steering ZF, hydraulic steering with power assistance(left hand drive)
Cab

HW76 one sleeper, with A/C, German VDO instrument and electronic controlled system, four-point support fully floating spring suspension +shock absorbers with transverse stabilizer, both the drive seat and the co-driver seat have the double locking organization safety belts, exterior sun visor, inner side sun shield, the alarming system

of the alternator when there is something wrong.
FrontAxle HF9 with drum brake
RearAxle HC16 x2 32000kg payload capacity
Suspension front: 10 multi-leaf spring; back: 12 multi-leaf spring
Rim|Tyres 13R22.5 Radial tubeless tire,11units(10tires and 1spare tire),
Lift of cargo box ventral lift strenghened T type
Cargo box internal dimensions 5800x2300x1500mm 20cbm, 35tons payload capacity
Thickness of cargo box Floor:8mm,Side:6mm.
Option: both can be thicken according to clients requirements.
Oil Tank 300L aluminum material oil tank
Color white,yellow,green,red(optional)
Note: Some of the configuration can be changed according to your special requirement.


Sinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 CabinSinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 CabinSinotruk Howo 7 Heavy Duty Dump Truck 6x4 30 - 40T 16m3 Capacity Hw76 Cabin

Other products:

Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( 54873020, 54798871, 54798867, 54633157, 54622108, 54621778, 54621524, water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
