Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD
Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD
Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD
Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD
Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD
Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD
Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD
Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD
Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD
Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD
Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Price :
NEgotiable
Supply Ability :
1000 units/month
Delivery Time :
Within 35 days
Packaging Details :
Waxed on deck or in container
Driving mode :
8x4
Dimension :
10245x2496x3450mm
Lifting mode :
HYVA Cylinder Front Lifting
Wheel Base :
1800+3500+1350mm
Loading tons :
40t-50t
Engine :
336,371,420hp
Gearbox :
HW19710
Description

Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine

Advantage

1. WEICHAI 340,380HP
2. EATON clutch
3. America parts
4. EATON/ FULLER gearbox
5. Front lift or middle lift
6. Steel Cabin for comfortable drive
7. WABCO valve
8. USA TRW steering
9. NORGREN solenoid valves
10. KOREAN GLOBAL free-maintenance battery
11. American TFLOCK self-locking nuts
12. American WOODWARD speed governor
13. GEMAN retarder
14. American TUTHILL cable
15. CVG American driver seat
16. American TENNECO shocker
17. AMP plug connector

specifications

Products Technical Specification
Type 8*4 Dump truck
Brand Sinotruk-HOWO
Cab HW76, Half row,With A/C,sleeper
Vehicle Description
Overall dimensions(mm) 11145*2496*3190
G.V.W (kg) 31000
Curb weight(vehicle) (kg) 15600
Loading capacity (kg) 50000-65000
Max speed (Km/h) 75
Engine
Engine model WD615.47
Maximum power 273kw / 371hp
Displacement (lit) 9.726
Engine Manufacturer China Heavy Duty Truck Group Co., Ltd.
Chassis Description
Chassis Model ZZ3317N4667A
Wheel base 1800+4600+1350
F/R track base(mm) 2022/1830
F/R overhang(mm) 1500/1005
Approach/Departure angle(°) 19/46
Spring plate 14/ 13/14/13/12
Front axle / rear axle HF9/HC16
Type of fuel Diesel
Transmission HW19710,10-Speed
Brake System Air braking
Operation control system Power steering
Electric system 24V
Tire specification 12.00-20
Up-parts Description
Van dimensions(mm) 8200*2300*1500/1800 25CBM TO 33CBM
Van description

Equipped with material of carbon steel,
side 6mm thickness;bottom 8mm thickness
Equipped with fornt hydraulic ram, single door.
Optional Configuration
Cargo body thickness,side door,and HYVA brands hydraulic cylinder,etc.


Photos
Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHDSinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD

Other Construction machinery can be provide according to your request, freely contact me for the informations and quotations.

The main products we deal with now are SINOTRUK HOWO, XCMG, SHANTUI, ZOOMLION and SANY.
Truck series:

1.dump trucks; cargo trucks
2. tractor trucks;
3. tanker trucks,( water tanker and oil tanker)
4. mixer trucks and concrete pump truck
5. mine dump trucks( 4x2 off-road mine tipper, 6x4 70T mine dump truck, 6x6 articualted dump trucks)
6. full drive trucks( 4x4. 6x6 and 8x8 Trucks)
7, garbage trucks( garbage compector truck, suction trucks)
8. truck cranes(normal road truck crane, truck mounted crane)
9. special trucks( wrecker trucks, military trucks...)
10. truck trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11. truck spare parts( howo, howo A7, golden prince all series trucks parts supplying)

Machine series:

1.Wheel loader,Backhoe loder, brick making machine

2.Roller,

3.Motor Grader,

4.Bulldozer,

5.Excavator,

6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane),

7,forklift and 45t contain reach stacker

8,paver and so on

Sinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHDSinotruck Front Hydraulic Lifting 8 x 4 Heavy Duty Dump Truck 371HP Engine, LHD/RHD


International Market:Ethiopia/Africa/Uganda/Chad/Zambia/Tanzania/Liberia/Myanmar
/Cambodia/Thailand/Malaysia
