40T-60T Bulk Cement Tank Semi Trailer Semi-Trailer Semi-Trailer Powder Material Transporter

40T-60T Bulk Cement Tank Semi Trailer Semi-Trailer

Description:

Powder material transport vehicle is also called bulk cement truck.
It is composed of special vehicle chassis, bulk cement truck tank, gas pipeline system, automatic unloading device and other parts. It is suitable for bulk transportation of fly ash, cement, lime powder, ore powder, granular alkali and other powder and dry materials with a particle diameter not greater than 0.1mm.
Mainly used for cement factories, cement warehouses and large construction sites, which can save a lot of packaging materials and loading and unloading labor.

Specification:

Photos:

Features:
It is suitable for the transportation and air pressure unloading of powder dry materials such as fly ash, cement, lime powder, ore powder, etc. whose particle diameter is not more than 0.1mm.

When the vertical height of unloading reaches 15m, the horizontal conveying distance can reach 5m.

The semi-trailer powder material transporter uses the power of its own engine to drive the on-board air compressor through the power take-off, and sends the compressed air into the air chamber at the lower part of the sealed tank through the pipeline to suspend the cement on the fluidized bed into a fluid state. , When the pressure in the tank reaches the rated value, the discharge butterfly valve is opened, and the fluidized cement flows through the pipeline for transportation.

Tank
The tank structure consists of a head, a variable section tank, and a main tank.
The upper and lower halves of the main tank are semi-circular, the middle is connected by a straight section,

and the connection with the head is excessively variable cross-section.

It needs cutting and blanking, splicing and welding, and overall rolling.

The variable-section tank needs gas cutting and rolling.

The main tank and the variable-section tank are butted and then docked with the head.

Under normal circumstances, compared with the volume of the normal straight tank,

its volume can be increased by about 2-3 cubic meters.
