9-12m3 336hp 6x4 Large Concrete Mixer Cabin HW76 One Sleeper With Air - Conditioner
9-12m3 336hp 6x4 Large Concrete Mixer Cabin HW76 One Sleeper With Air - Conditioner
9-12m3 336hp 6x4 Large Concrete Mixer Cabin HW76 One Sleeper With Air - Conditioner
9-12m3 336hp 6x4 Large Concrete Mixer Cabin HW76 One Sleeper With Air - Conditioner
9-12m3 336hp 6x4 Large Concrete Mixer Cabin HW76 One Sleeper With Air - Conditioner
9-12m3 336hp 6x4 Large Concrete Mixer Cabin HW76 One Sleeper With Air - Conditioner
9-12m3 336hp 6x4 Large Concrete Mixer Cabin HW76 One Sleeper With Air - Conditioner
9-12m3 336hp 6x4 Large Concrete Mixer Cabin HW76 One Sleeper With Air - Conditioner
Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
500 Unit/Units per Month
Delivery Time :
Within 35 days
Packaging Details :
In nude
Brand :
HOWO
Condition :
New
Wheel base :
3800+1400mm
Cabin :
HW76, one sleeper with air-conditioner
Engine :
WD615.69, Euro 2, 371HP
Steering :
ZF8118, power steering with hydraulic system
Description

SINOTRUK HOWO 8m3/9m3/10m3/12m3 336hp Concrete Mixer

SINOTRUK HOWO 8m3/9m3/10m3/12m3 336hp Concrete Mixer Truck With Good price

Truck With Good price

1). Using hydraulic transmission device, do not rely on external force, easy to use, continuous rotation of the tank during transport, commercial concrete does not precipitate, not segregation.
2). Easy to operate, a handle to achieve centralized control of mixing tank, the configuration mature and reliable, easy maintenance.
3). Low noise, no smoke, safe and reliable.
4). The use of high-intensity wear-resistant steel plate mixing tank, durable.
5). Unique inlet setting, easy to spread material.
6). Small size, transport flexibility, easy operation and maintenance, power consumption, energy-saving effect is remarkable.
7). Blade design is reasonable, the discharge residue rate is low.

Specification for concrete mixer truck

Chassis Model ZZ1257N3841W ( Left Hand Driving Type)
Dimension (L×W×H)mm 9025*2496*3950mm
Wheel base mm 3800+1400
Cabin HW76, one sleeper with air-conditioner.
Engine WD615.69, Euro 2, 371HP
Transmission HW15710, 10F & 2R
Steering ZF8118, power steering with hydraulic system.
Front Axle HF9, 1x9000 KGS
Rear Axle HC16, 2x16000 KGS
Tyres 1200R20, 10+1tyres
Frame 8+5 mm double strengthen frame
Fuel Tank Volume 300L
Mixer Pump Eaton (USA Brand)
Motor Eaton (USA Brand)
Speed Reducer Bonfiglioli (Italy Brand)
Agitating Capacity 12 Cubic Meters
Geometric Volume 16.5m3
Water Tank Volume 400L
Drum rotating 11°
Agitator rotaion speed 0-18r/min
Feeding speed >3m3/min

Picture for you reference
