Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Specifications
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
6000 units per week
Delivery Time :
Within 35 days
Packaging Details :
Nude
Brand Name :
CIVL
Name :
30 Tons Tipper Truck
Truck type :
Diesel Engine
Feature :
Low Noise
Axle :
STR
Load capacity :
30T
Tire :
1200R20
Description

Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty

30 Tons Tipper Truck Description:

30 Tons Tipper Truck is China's heavy truck integrated use of the current world of advanced automotive technology, the choice of proven components assembly developed a series of products.

HOWO6 × 6 all-wheel drive can be used as transport vehicles, various types of transport, fuel trucks, all types of transportation equipment chassis, suitable for off-road transport, towing equipment, transport operations oil, mining, forestry, fire fighting equipment and various types of special vehicle modification needs .
30 Tons Tipper Truck Engine

High strength/ high rigidity/ long life block: vermicular cast iron body, similar strength cast steel, similar heat dissipation potential gray iron, strong anti-thermal deformation, high cost, can be adopted in few high end engines in the world due to its core technology.

1). Good economy: high-explosive pressure and optimized injection and combustion system, ensuring its low specific oil consumption at a wide range of sppds, Minimum specific oil consumption is 186/kwh.

2). Low nose: noise reaches the international level.

3). High-integration: volume of spare parts reduced 25% compared with the similar products in the world, highly reducing the failure points.

4). Long life of B10: reach the most advanced world level of heavy duty truck, 1.5 million km.

5). Long oil change interval: for Euro IV oil, the first oil change mileage( oil change interval) for the road vehicles since left factory shall be up to 100.000 km, for the oil selling bu Petrochina and Sinopec. it shall be up to 60.000 km, greatly reducing the cost.

30 Tons Tipper Truck Specifications:

Model

6x6 dump truck Based on using STR technology

Gear box

American technology

Max torque:1600NM

Model:

HW15710C

Speed:

15speed, 2reverse

Axle(front/rear)

Front axle

9T STR technology non-driving steering axle

Tandem

16T STR technology double reduction, hub redactor driving axle

Clutch

D430 diaphragm type, single dry frictional disc, hydraulic boosting

Brake

Service brake: Double circuit pneumatic brake

Parking brake: Spring-Power drum brake

Engine brake: Engine exhaust brake (EVB)

Steering

ZF8118, driver sit at the Left hand side, RHD is optional

Electric Equipment

Operating voltage:

24Vnegative grounded

Starter:

24V,5.4KW

Alternator

28V,758W

Battery voltage

12V/135Ah, cigar lighter

Frame

Strengthen steel frame, designed according to tough road condition.

Tyre

10+1 spare tyre with rim

12.00-20 bias tyre

Suspension system: Strengthen heavy duty Leaf spring type

Front/Rear

10/12

Dump body: type of body :

Inside size of Body(mm): 5170x2300x1500, 8x6mm (thickness of floor and rail of the dump body)

Lifting type: HYVA front lifter type hydraulic system

Overall dimension(mm): 11868x2496x3250 (Length x width x height)

Wheelbase

3800+1400mm

Track:

Front/Rear

2036/1850

Approach/Departure angle

28/30

Front /Rear overhang

1525/1654

Max speed

90km/h

Curb weight:

12190kg

Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy DutyDiesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy DutyDiesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy DutyDiesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
