Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
2000units/year
Delivery Time :
Within 35 days
Packaging Details :
nude
color :
red
warranty :
1year
condition :
new
emission stander :
2
Description

China Supplier HOWO 8X4 dump truck / 31t dump truck dimensions

Truck Model : ZZ3317N4267A
Truck Brand : SINOTRUK – HOWO
Driving Style : Left Hand Driving
Dimension (L*W*H)(unloaded)(mm) : 10825×2496×3190
Cargo body size (L*W*H, mm) : 7800×2300×1050
Cargo thickness (mm): Bottom: 8
Side: 6
Lift type of Carriage : Front lifting
Approaching angle / Departure angle (°) : 19/22
Overhang(front / rear)(mm) : 1500/1975
Wheel base (mm): 1800+4200+1350
Max speed (km/h) : 75
Curb weight (kg) : 15480
Loading Weight (kg) : 31000
Fuel tanker capacity (L) : 300
Fuel consumption (L/km) : 28L/100
Clutch : Single-plate dry clutch Φ 430mm
Fuel type : Diesel
Horse Power, max (kw/rpm) : 371HP
Emission : EURO II
Transmission : HW15710 , 10 forwards and 2 reverse
Brake system : Dual circuit compressed air brake
Parking brake :

spring energy, compressed air operating on rear
wheels
Auxiliary brake : Engine exhaust brake
Steering system : ZF8118 hydraulic steering with power assistance
Front axle : HF9 , Steering with double T-cross section beam
Rear axle :

HC16,Pressed axle housing,central double reduction
with differential locks between axles and wheels
Color : Optional( White , Red , yellow or as your needs )
Tyre : 12.00R20
Cab :

HOWO76 cab,single sleeper with air conditioner
all-steel forward control,55º hydraulically tiltable
to the front,2-arm windscreen wiper system with
three speeds,laminated windscreen with casted-inradio
aerial,hydraulically damped adjustable driver’s seat
and rigid adjustable co-driver’s seat,with heating and
ventilating system,outer sun visor,adjustable
roof flap,with stereo radio/cassette recorder safety
belts and adjustable steering wheel,air horn,with 4-point support fully floating suspension and shock
absorbers



Left Hand Driving 8X4 Tipper Truck SINOTRUCK HOWO ZZ3317N4267A 50 - 60T Dump TruckLeft Hand Driving 8X4 Tipper Truck SINOTRUCK HOWO ZZ3317N4267A 50 - 60T Dump Truck

Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
