Cimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil Tank
Cimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil Tank
Cimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil Tank
Cimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil Tank
Cimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil Tank
Cimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil Tank
Cimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil Tank
Cimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil Tank
Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
2000units/year
Delivery Time :
Within 35 days
Packaging Details :
nude
material :
Q235
axle :
fuwa
thickness :
3mm
Description

Cimc 30000L 3axle aluminum or stainless steel water milk oil tank tanker semi trailer

Tank Body
Shape Optional (Round or Square)
Dimension 12000*2400*3800mm
Tare weight About 8000Kg-12800Kg
Tanker body material 5mm or 6mm /carbon steel or stainless steel or Aluminium alloy
End plate 5mm or 6mm/carbon steel or stainless steel or Aluminium alloy
Manhoel cover

Carbon steel or Aluminum alloy API
manhole cover ,500mm
Bottom valve Aluminum API Pneumatic Bottom Valve
Discharging valve Diameter is 3 or 4 inch
Compartments 1-5 isolated compartments, Optional
Discharging Pipe 4" rubber hose,2 pcs,6m/each
Cat walk With (Common model or special design)

Chassis
Main Beams

Welding design or special design I beam ,or connected by bolts and nuts
Q345 carbon steel material
Axle 2 or 3 axles, BPW/FUWA or China brand
Landing Gear JOST 28T or China brand 28T
King Pin 2 inch or 3.5 inch(according to fifth wheel)
Suspension Mechanical suspension(Germany or American type)/air suspension
Leaf spring 90mm*13mm*10 or 100mm*12mm*12(customized)
Tire 12R22.5;11.00R20;12.00R20;(customized)
No. of the Tire 12
ABS Optional
Painting

Complete Chassis and blasting to clean rust,1 coat of anticorrosive prime,
2 coats of final paint
Accessories One standard tool box and a set of spare tire carrier

Cimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil TankCimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil TankCimc 30000L 3 Axle Semi Trailer Trucks With Aluminum Or Stainless Steel Water Milk Oil Tank

Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
