3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis
3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis
3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis
3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis
3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis
3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis
3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis
3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis
Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Supply Ability :
100 units per Month
Delivery Time :
Within 35 days
Packaging Details :
Nude
Axle :
3* 13t Fuwa
Load capacity :
20T-80T
Size :
Produce accroding to customer's requirement
Material :
Aluminum / Alloy
Use :
Truck Trailer
Color :
Custom's Requirement
Name :
container chassis semi trailer
Description

3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis

Specifications

Other Truck and trailer can be provide according to your request, freely contact me for the informations and quotations.

DORIN (Ms)

1:mail : roadmachine@road-machine.com

2:Tel : 86+13210589366

3:Skype : 008613210589366

4:The company :SINO VEHICLE&EQUIPMENT COMPANY LTD

Loading Capacity:30ton,40ton,50ton,60ton,70ton,80ton,optional

Axle: Fuwa brand,L1 brand,HJ brand,BPW brand,SKF brand optional.

Length:7500mm,12500mm,13000mm,15000mm,18000mm optional

Tyre: 1200R20,1200R22.5,1100R20,385/60R22.5tubeless type or steel belted type is optional,single tyre or double tyre is optional

Tyre brand:Triangle brand,ChengShang brand,Double Happiness brand,Bridgestone brand,Double Coin brand,Ling Long brand

Suspension:Germany mechanical suspension/bogie suspension/ airbag suspension

Twist lock:4 units,8 units,12 units.

Pls Notice:this is for your consideration only

Actual data depend on your actual requst!

Trailer Model

3 Axle flatbed Container Semi Trailer

Model Number

SCD9400TJZ

Function

Carry 40ft or 2*20ft container or other stuff

Overall Dimension

(Lx W x H)(mm)

12500*2500*1550

Tare Weight(KG)

6350

Loading Weight( KG)

40000

Total Weight(KG)

46350

Axle Brand

13TON Axle FUWA Brand

Axle Number

Three

Wheelbase(mm)

7450+1310+1310

Suspension system

Leaf Spring Suspension

The material of Main beam

The height of the beam is 500 mm.

Platform plate

3mm Diamond plate

Container Twist Locker

12pcs container lock

Tire Type and quantity

12R22.5 12units,Triangle brand

Traction Pin

50MM or 90MM

3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis3 Axle 2 x 20ft / 40ft 12500mm Flatbed Container Semi Trailer / Trailer Chassis
