Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump
Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump
Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump
Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump
Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump
Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump
Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump
Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump
Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump
Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump
Specifications
Brand Name :
SHMC
Model Number :
ZB series
Certification :
CE ISO
Place of Origin :
CHINA
MOQ :
1
Use type :
Drainage Irrigation Drain Floods
Moveble :
Portable Pump
Size :
Small Compact
Power :
Gas/diesel
Description
name Self suction direct high speed centrifugal pump
Model QGZ25-30A
Pump Inlet diameter(mm) 25
The diameter of the outlet (mm) 25
flow(m³/h) 8
Lift(m) 30
Suction lift(m) 8
Engine Model 1E36F-2A
Power(kw/r/min) 0.9/6500
Displacement(cc) 32.6
Package Power(kg) 7.5
Package Size(mm)

400×330×390

Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump

Name Self suction direct high speed centrifugal pump
Model QGZ40-35E
pump Inlet diameter(mm) 40
The diameter of the outlet(mm) 40
Flow(m³/h) 15
lift(m) 35
Suction lift(m) 8
Engine Model 1E40F-2E
power(kw/r/min) 1.1/6500
Displacement(cc) 42.7
Package Net Weight(kg) 11
Package Size(mm) 400×330×490


Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump

Model 50ZB30-3.2Q
Mating power 168F
The diameter of the outlet(mm) 50
Flow(m³/h) 35
Suction lift(m) 8
MaxLift(m) 30
Weight(kg)(kg) 22
Package Size(mm)

500×387×430

Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump

Model 80ZB20-4.0C
Mating power C178F
The diameter of the outlet(mm) 80
Flow(m³/h) 50
Suction lift(m) 8
Maxlift(m) 20
Weight(kg) 47
External Dimension(mm) 600×490×570
Three cylinder pump
Model Mating power Pressure(Mpa) Flow(m³/h) Range(m) power(kw/r/min) Net weight(kg) Package Dimension(mm)
3WZ-30 FujiEX17 1.5-3.5 30 18 2.94/3600 28 1600×340×440

Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump

Model ZB100
Flow(cbm) 96
Suction Length(m) 8
Lift(m) 16
Discharge(ml) 270
Net Weight(Kg) 50
Power 177F
Water Outlet Diameter(mm) 100
Package Size(mm) 640*500*580mm

Diesel Power Drainage Irrigation 1 / 1.5 / 2 / 3 / 4 Inch Portable Water Pump

- performance characteristics and applicable scope: this kind of pump belongs to the ground drainage and irrigation machinery, and has the characteristics of small volume, light weight, compact structure, convenient operation;
Can be widely used in farmland, garden irrigation, domestic water, as well as construction, industrial and mining enterprises to the water supply and drainage, etc..

Extraordinary power, fashionable design, beautiful and of lower vibration, lower noise and higher lift and strong suction.
The water pump has gained CE certificates.

Optimization of the design of the spiral and the impeller, reduce the Sheung Shui time, strong power output and high lift.

This kind of pump belongs to the ground drainage and irrigation machinery, and has the characteristics of small volume, light weight, compact structure, convenient operation; can be widely used in farmland, garden irrigation, domestic water, as well as the construction, industrial and mining enterprises drainage.
