Shangchai Engine Euro 2 New Telescopic Boom Crane QY25K-II , 25 Ton Mobile Truck Crane
Shangchai Engine Euro 2 New Telescopic Boom Crane QY25K-II , 25 Ton Mobile Truck Crane
Shangchai Engine Euro 2 New Telescopic Boom Crane QY25K-II , 25 Ton Mobile Truck Crane
Shangchai Engine Euro 2 New Telescopic Boom Crane QY25K-II , 25 Ton Mobile Truck Crane
Shangchai Engine Euro 2 New Telescopic Boom Crane QY25K-II , 25 Ton Mobile Truck Crane
Shangchai Engine Euro 2 New Telescopic Boom Crane QY25K-II , 25 Ton Mobile Truck Crane
Shangchai Engine Euro 2 New Telescopic Boom Crane QY25K-II , 25 Ton Mobile Truck Crane
Shangchai Engine Euro 2 New Telescopic Boom Crane QY25K-II , 25 Ton Mobile Truck Crane
Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10units per week
Delivery Time :
Within 35 days
Packaging Details :
nude
Type :
Straight Arm
Dimension :
12650*2500*3380mm
Total Weight in Travel :
29400kg
Engine Model :
Shangchai Sc8dk280q3
Rated Power :
206/2200kw/(R/Min)
Max. Travel Speed :
75km/H
Min. Turning Diameter :
21.5m
Max. Rated Total Lifting Capacity :
25t
Max. Lifting Torque :
1010kn.M
Boom Full Extension Time :
100s
Description

XCMG 25 Ton Mobile Crane Telescopic Boom Truck Crane (QY25K-II)

QY25K truck crane was developed by our company in 2000. Through constant upgrade, the travel and working performance are greatly improved. The chassis is three-axle which has strong power and cross-country capacity. The jib is optimized octagon section, which has excellent lifting capacity. The control system adopts hydraulic proportional (mechanical) control technique.


Dimension
Unit		 QY25K-II

Overall length
mm
12650

Overall width
mm
2500

Overall height
mm
3380

Weight

Total weight in travel
kg
29400

Front axle load
kg
6200

Rear axle load
kg
23200

Power

Engine model
SC8DK280Q3 / WD615.329(domestic III)

Engine rated power
kW/(r/min)
206/2200 213/2200

Engine rated torque
N.m/(r/min)
1112/1400 1160/1400

Travel

Max. travel speed
km/h
75

Min. turning diameter
m
21.5

Min. ground clearance
mm
275

Approach angle
°
16

Departure angle
°
13

Max. grade ability
%
30

Fuel consumption for 100km
L
≈37

Main performance

Max. rated total lifting capacity
t
25

Min. rated working radius
mm
3000

Turning radius at turntable tail
m
3.065

Max. lifting torque
kN.m
1010

Base boom
m
10.7

Fully extended boom
m
34.19

Fully extended boom+jib
m
42.15

Longitudinal outrigger span
m
5.14

Lateral outrigger span
m
6

Working speed

Boom luffing time
s
75

Boom full extension time
s
100

Max. swing speed
r/min
≥2.5

Max. speed of main winch (single rope)
m/min
≥120

Max. speed of aux. winch (single rope)
m/min
≥120



www.road-machine.com
www.china-sinotruck.com

The main products we deal with now are SINOTRUK HOWO, XCMG, SHANTUI, ZOOMLION and SANY.
Truck series:

1.dump trucks; cargo trucks
2. tractor trucks;
3. tanker trucks,( water tanker and oil tanker)
4. mixer trucks and concrete pump truck
5. mine dump trucks( 4x2 off-road mine tipper, 6x4 70T mine dump truck, 6x6 articualted dump trucks)
6. full drive trucks( 4x4. 6x6 and 8x8 Trucks)
7, garbage trucks( garbage compector truck, suction trucks)
8. truck cranes(normal road truck crane, truck mounted crane)
9. special trucks( wrecker trucks, military trucks...)
10. truck trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11. truck spare parts( howo, howo A7, golden prince all series trucks parts supplying)

Machine series:

1.Wheel loader,Backhoe loder, brick making machine

2.Roller,

3.Motor Grader,

4.Bulldozer,

5.Excavator,

6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane),

7,forklift and 45t contain reach stacker

8,paver and so on
