XCMG brand road roller, XS122, operating weight 12000kgs/12t, fully hydraulic single steel wheel vibratory roller
Advantages:
XS122 is a medium-sized hydraulic driven vibratory roller developed on the basis of the XS120 full hydraulic single-drum vibratory roller with the largest export volume in China. As one of the representative products of XCMG hydraulic vibratory roller, the compaction performance, driving performance, handling performance, reliability and maintenance performance all represent the highest level of domestic roller.
Broaden horizons
· Lateral column moved to the side, the entire glass front and rear cab design, no shadow defects in the working direction before and after, providing drivers with extraordinary vision.
Comfortable operating environment
Full hydraulic drive, easy to operate and convenient. Ergonomics-based control panel, with suspended seat, car radio, make driving more comfortable.
Standard heating and cooling air conditioning also provides a comfortable operating environment.
Excellent compaction performance
· Reliable electrical system
Comprehensive security
Excellent maintenance performance
Specification:
Brand | XCMG |
Operating weight | 12000kg |
Compaction width | 2130mm |
Engine power | 93kw |
Engine brand | Cummins |
Engine model | 4B3.9 |
Speed | 2200r/min |
Engine type | water-cool, turbo-charge |
Front wheel mass | 6700kg |
Front wheel static load | 308N/cm |
Vibratory frequency | 35Hz |
Amplitude(H): | 1.8mm |
Amplitude(L): | 0.9mm |
Amplitude excitation force(H) | 290kN |
Amplitude excitation force(L) | 180kN |
Drum diameter | 1523mm |
Drum width | 2130mm |
Driving speed | 0~10.4km/h |
Gradeability | 45% |
Turning angle | 30° |
Swing angle | 10° |
Min.turning radius | 6800mm |
