SD08 Shantui Hydraulic Bulldozer Sd08 Mini Bulldozer Cummins Engine, ROPS Cabin Front Blade, Rear Ripper Yellow Color
SD08 Shantui Hydraulic Bulldozer Sd08 Mini Bulldozer Cummins Engine, ROPS Cabin Front Blade, Rear Ripper Yellow Color
SD08 Shantui Hydraulic Bulldozer Sd08 Mini Bulldozer Cummins Engine, ROPS Cabin Front Blade, Rear Ripper Yellow Color
SD08 Shantui Hydraulic Bulldozer Sd08 Mini Bulldozer Cummins Engine, ROPS Cabin Front Blade, Rear Ripper Yellow Color
SD08 Shantui Hydraulic Bulldozer Sd08 Mini Bulldozer Cummins Engine, ROPS Cabin Front Blade, Rear Ripper Yellow Color
SD08 Shantui Hydraulic Bulldozer Sd08 Mini Bulldozer Cummins Engine, ROPS Cabin Front Blade, Rear Ripper Yellow Color
Specifications
Brand Name :
Shantui
Model Number :
SD08
Certification :
CCC ISO
Place of Origin :
China
MOQ :
1 unit
Price :
Negociable
Supply Ability :
800 unit /month
Delivery Time :
Within 40 days after get the deposit
Packaging Details :
Waxed on deck or in container
Dimension :
8478 x 4314 x 3970 mm
Ground pressure(including ripper) (KPa) :
112Kpa
Gradient :
30°/25°
Dozer :
Straight Dozer
Colour :
According to your request
Max. digging depth (mm) :
614 mm
Description

SD08 Shantui Bulldozer With 2.2 CBM Dozing Capacity And Cummins Engine

Descriptions

SD08 bulldozer: semi-rigid elasticity suspending, hydraulic-mechanical transmission, elevated sprocket track type, wholly hydraulic operation, pilot hydraulic controlling

blade operation, modular designing components easily for maintaining, portable laborsaving nicety

man-machine designing controlling system, electric monitoring, ROPS cabin, many optional equipments,

broadly used in transport, desert, oil field, power station, mine, swamp etc. large-scale stone construction.

You can select original American Cummins engine, emission standard meet with Tire 3 with lower fuel

consumption and stronger power output.

Specifications

ITEM UNIT SD08-3
L×W×H (Ripper not included) mm 3973×2553×2785
Operating weight (Ripper not included) t 7.65
Engine - Weichai WP4G90E235
Rated power kW/rpm 63/2350
Gradeability ° 30
Blade type - Straight tilt blade
Blade width mm 2553×890
Dozing capacity m3 2.02
Ma× drop below ground of blade mm 383
Lift height of blade mm 850
Ripper type - -
Ripping depth of ripper mm -
Lifting height of ripper mm -
Number of carriers (each side) - 1
Number of track rollers (each side) - 6
Number of track shoes (each side) - 41
Width of track shoe mm 460
Track gauge mm 1450
Ground length and ground pressure mm/MPa 2185-0.038
Pitch mm 154.25
Forward speed km/h 0–2.53
0–4.55
0–7.57
Reverse speed km/h 0–2.76
0–4.95

Photos

SD08 Shantui Hydraulic Bulldozer Sd08 Mini Bulldozer Cummins Engine, ROPS Cabin Front Blade, Rear Ripper Yellow ColorSD08 Shantui Hydraulic Bulldozer Sd08 Mini Bulldozer Cummins Engine, ROPS Cabin Front Blade, Rear Ripper Yellow ColorSD08 Shantui Hydraulic Bulldozer Sd08 Mini Bulldozer Cummins Engine, ROPS Cabin Front Blade, Rear Ripper Yellow Color

Other Construction machinery can be provide according to your request, freely contact me for the informations and quotations.
