Professional 12 Wheel Water Delivery Truck , Special Project Vehicle，38.5 m³，8x4drive
Professional 12 Wheel Water Delivery Truck , Special Project Vehicle，38.5 m³，8x4drive
Professional 12 Wheel Water Delivery Truck , Special Project Vehicle，38.5 m³，8x4drive
Professional 12 Wheel Water Delivery Truck , Special Project Vehicle，38.5 m³，8x4drive
Professional 12 Wheel Water Delivery Truck , Special Project Vehicle，38.5 m³，8x4drive
Professional 12 Wheel Water Delivery Truck , Special Project Vehicle，38.5 m³，8x4drive
Professional 12 Wheel Water Delivery Truck , Special Project Vehicle，38.5 m³，8x4drive
Professional 12 Wheel Water Delivery Truck , Special Project Vehicle，38.5 m³，8x4drive
Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
1000 sets / every month
Delivery Time :
Within 35 days
Packaging Details :
IN NUDE
Approach/Departure angle :
16/14
Axle nos :
4
Tyre nos :
12
Steering model :
Steering wheel
Description

Low density powder material truck;Effective volume of tank: 38.5 cubic meters,12 wheel

Effective volume of tank: 38.5 cubic meters, tanks overall length: 9600 mm, straight segment of length: 8760 mm, and tank diameter: 2490 mm, transport medium for: polyethylene powder, medium density is: 400 kg/m3. Side and bottom side protective device made of Q235A, connections are bolted connection, after the section size of the lower protective device for (width x height) : 100 mm * 100 mm, and height from the ground 500 mm. ABS system models for 4460046300, only USES the wheel base of 1800 + 4600 + 1350, 1800 + 4575 + 1400 of the chassis. Along with the chassis being optional sun shade, high bridge. Should be installed with the motion of the satellite positioning function recorder.

The Low density powder material truck's main parameters as below

Vehicle name Low density powder material truck
Vehicle type Special vehicle
Vehicle model SHMC5316GFLD1
Engine model MC07.31-40 Engine power 228
MC07.34-40 248
Engine displacement 6870 Engine manufacturers SINOTRUK
6870
Overall dimensions(L/W/H) 11990*2496*3870 Type of fuel Diesel
Total weight(Kg) 31000 Front passenger(person) 2
Curb weight(kg) 16160 Permitted capacity 14710
Approach/Departure angle 16/14 Front/Rear overhang 1430/2810
1430/2785
Wheelbase(mm) 1800+4600+1350 Axle load 6500/7000/17500
1800+4575+1400
Axle nos 4 Max. drive speed (km/h) 110
fuel consumption 41.7,42.0 Spring nos 3/3/4,3/3/5,3/3/10,3/3/-,11/11/10
Tyre nos 12 Tyre specification

10.00-20,10.00R20,11.00-20,11.00R20,12R22.5,

295/80R22.5
Front wheel track 2015/2015,2035/2035 Rear wheel track 1830/1830
Steering model Steering wheel
Chassis standard GB17691-2005EUROIV,GB3847-2005
Identification code LZZ8BXNF******

Professional 12 Wheel Water Delivery Truck , Special Project Vehicle，38.5 m³，8x4drive

tank car, watering cart, sprinkler,sprinkler truck ,water spraying

water tank truck, water tank lorry, tank water, tanker, tank truck, tank apparatus, water tanker
fuel tank car,oil tank truck,tank truck ,tanker,oil tank truck, oil tanker, refuel truck, refuelling truck,oil truck,fuel truck,petrol tanker, fuel vehicle, fuelling vehicle, fuel tanker truck,fuel-transportvehicles
