19.5 Cubic Meters Big Capacity Water Tanker Truck For Municipal Engineering,6x4 drive
19.5 Cubic Meters Big Capacity Water Tanker Truck For Municipal Engineering,6x4 drive
19.5 Cubic Meters Big Capacity Water Tanker Truck For Municipal Engineering,6x4 drive
19.5 Cubic Meters Big Capacity Water Tanker Truck For Municipal Engineering,6x4 drive
19.5 Cubic Meters Big Capacity Water Tanker Truck For Municipal Engineering,6x4 drive
19.5 Cubic Meters Big Capacity Water Tanker Truck For Municipal Engineering,6x4 drive
Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
1000 sets / every month
Delivery Time :
Within 35 days
Packaging Details :
IN NUDE
Total weight(Kg) :
25000
Axle load :
7000/18000
Approach/Departure angle :
20.5/17
Steering model :
Steering wheel
Description

Refueling truck,Effective volume of tank: 19.5 cubic meters

Effective volume of tank: 19.5 cubic meters, the shape of tank size (length x width x height) (mm) : 6600 * 2385 * 2385;Medium: gasoline, medium density: 700 kg/m3.Side and bottom side protective device made of Q235A, connections are bolted connection, after the section size of the lower protective device for (width x height) : 50 mm * 100 mm, and height from the ground is: 550 mm.Only use equipment front axle disc brake, speed limiter, ABS and radial tyre chassis.ABS system models for 4460046300, the vehicle installation running recorder with satellite positioning functions.Options high bridge.

The oil truck's main characteristic as below

Vehicle name Oil truck
Vehicle type Special vehicle
Vehicle model SHMC5251GJYD
Engine model D10.28-40 Engine power 206
D10.31-40 228
Engine displacement 9726 Engine manufacturers SINOTRUK
9726
Overall dimensions(L/W/H) 9400*2496*3150,3630 Type of fuel Diesel
Total weight(Kg) 25000 Payload capacity 4
Curb weight(kg) 11805 Permitted capacity 13000
Spring nos 4/-,10/-,10/12 Front passenger(person) 3
Approach/Departure angle 20.5/17 Front/Rear overhang 1320/2380
Wheelbase(mm) 4350+1350 Axle load 7000/18000
Axle nos 3 Max. drive speed (km/h) 79
Tyre nos 10 Tyre specification 11.00-20,11.00R20 16PR,12.00-20 16PR,12.00R20 14PR,12R22.5 16PR,295/80R22.5 16PR,315/80R22.5 16PR
Front wheel track 20,222,041 Rear wheel track 1830/1830
Steering model Steering wheel
Chassis standard GB17691-2005EURO IV,GB3847-2005
Identification code LZZABLMF****** LZZABLNF******

19.5 Cubic Meters Big Capacity Water Tanker Truck For Municipal Engineering,6x4 drive

tank car, watering cart, sprinkler,sprinkler truck ,water spraying

water tank truck, water tank lorry, tank water, tanker, tank truck, tank apparatus, water tanker


fuel tank car,oil tank truck,tank truck ,tanker,oil tank truck, oil tanker, refuel truck, refuelling truck,oil truck,fuel truck,petrol tanker, fuel vehicle, fuelling vehicle, fuel tanker truck,fuel-transportvehicles
