Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
Specifications
Brand Name :
CIVL
Certification :
ISO 9001-2000, CCC
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
200000 units/month
Delivery Time :
Within 25 days
Packaging Details :
suitable package by container
Use :
House
Color :
Optional
Size :
According to Customer Requirement
Window :
Aluminum alloy
Door :
Steel Door,Security Door
Material :
Sandwich Panel
Type :
Customizable,prefabricated
Floor :
floor tile/composite board
Application :
Workshop
Wall :
sandwich pannel(50mm/75mm EPS)
Product name :
Container house
Description

container house price prefab modular container houses/homes/hotels

Manufacturing Technology

*** Material : full-color steel sandwich panel/75-100mm glass fiber sandwich panel,

***18mm thickness cement particle board .

The dimension and material of container house:

Structure Steel column Galvanized bending steel,160mm*160mm*2450mm t=2.0mm
Roof girder Galvanized square tube120x60x1.5/30x30x1.5
Roof secondary beam Galvanized rectangular tube,40mm*60mm t=1.5mm
Ground girder Galvanized extruded steel,5955mm*3000mm*148mm Galvanized square tube120x60x1.2/30x30x1.2
Ground secondary beam Galvanized rectangular tube,40mm*60mm t=1.5mm
Ground secondary beam Galvanized rectangular tube,80mm*80mm t=1.5mm
Surface treatment Environmental protection water-based paint, primer + topcoat≥80μm；Color no.:RAL9018
Roofing Roofing V970 color steel single tile t=0.34mm
Insulation cotton Glass wool, bulk density ≥14kg / m³ t=50mm
Suspended ceiling Aluminum-plated zinc color steel plate, color white gray t=0.4mm
floor Substrate + moisture-proof film Fire retardant fiberboard, density ≥1.2g / m³, flame retardant class B t = 15mm
Wall Color coated board material Double-sided aluminum-plated zinc color coated board, PE coating t=0.3mm
Insulation Flame retardant glass wool, bulk density ≥40kg / m³, flame retardant A grade, t = 50mm
Door Specification WxH=950mm*1960mm
Window Specification WxH=960mm*1000mm with Screen
Frame material Upvc window frame sliding series
Glass Normal Glass
Electricity Voltage 220V～250V,50Hz,3-stage,32A
Line Three-core cable = 4㎡, socket cable = 2.5㎡, lighting switch cable = 1.5㎡
breaker High breaking small circuit breaker with leakage switch
Light Two sets of single tube LED ceiling lights
Switch, socket 1 10A switch, 3 10A five-hole sockets, 1 16A three-hole air conditioning socket

Advantage:

1. Fast installation speed.

2. More economical.

3. Less geographical restrictions.

4. Long service life.

5. Safe and stable.

Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich PanelPrefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel

Prefab Modular Container Houses / Homes / Hotels Glass Fiber Sandwich Panel
