large Prefab Shipping Container / Office Prefabricated Storage Container Homes
large Prefab Shipping Container / Office Prefabricated Storage Container Homes
large Prefab Shipping Container / Office Prefabricated Storage Container Homes
large Prefab Shipping Container / Office Prefabricated Storage Container Homes
large Prefab Shipping Container / Office Prefabricated Storage Container Homes
large Prefab Shipping Container / Office Prefabricated Storage Container Homes
large Prefab Shipping Container / Office Prefabricated Storage Container Homes
large Prefab Shipping Container / Office Prefabricated Storage Container Homes
large Prefab Shipping Container / Office Prefabricated Storage Container Homes
large Prefab Shipping Container / Office Prefabricated Storage Container Homes
Specifications
Brand Name :
CIVL
Certification :
ISO 9001-2000, CCC
Place of Origin :
CHINA
MOQ :
5units
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
200000 units/month
Delivery Time :
Within 25 days
Packaging Details :
suitable package by container
Name :
Prefab Shipping Container
Color :
Customized
Window :
Aluminum alloy
Door :
Steel Door,Security Door
Material :
Sandwich Panel
Type :
Customizable,prefabricated
Application :
Workshop
Wall :
sandwich pannel(50mm/75mm EPS)
Description

prefab shipping container office prefabricated container homes storage container homes

Manufacturing Technology

*** Material : full-color steel sandwich panel/75-100mm glass fiber sandwich panel,

***Q235 strip steel frame structure

The dimension and material of container house:

Container house Length 5950mm(inner:5790mm)
Width 3000mm(inner:2830mm)
Height 2780mm(inner:2500mm)
Floor no. 1-3

Structure Steel column Galvanized bending steel,160mm*160mm*2450mm t=2.0mm
Roof girder Galvanized square tube120x60x1.5/30x30x1.5
Roof secondary beam Galvanized rectangular tube,40mm*60mm t=1.5mm
Ground girder Galvanized extruded steel,5955mm*3000mm*148mm Galvanized square tube120x60x1.2/30x30x1.2
Ground secondary beam Galvanized rectangular tube,40mm*60mm t=1.5mm
Ground secondary beam Galvanized rectangular tube,80mm*80mm t=1.5mm
Surface treatment Environmental protection water-based paint, primer + topcoat≥80μm；Color no.:RAL9018
Roofing Roofing V970 color steel single tile t=0.34mm
Insulation cotton Glass wool, bulk density ≥14kg / m³ t=50mm
Suspended ceiling Aluminum-plated zinc color steel plate, color white gray t=0.4mm
floor Substrate + moisture-proof film Fire retardant fiberboard, density ≥1.2g / m³, flame retardant class B t = 15mm
Wall Color coated board material Double-sided aluminum-plated zinc color coated board, PE coating t=0.3mm
Insulation Flame retardant glass wool, bulk density ≥40kg / m³, flame retardant A grade, t = 50mm
Door Specification WxH=950mm*1960mm
Window Specification WxH=960mm*1000mm with Screen
Frame material Upvc window frame sliding series
Glass Normal Glass
Electricity Voltage 220V～250V,50Hz,3-stage,32A
Line Three-core cable = 4㎡, socket cable = 2.5㎡, lighting switch cable = 1.5㎡
breaker High breaking small circuit breaker with leakage switch
Light Two sets of single tube LED ceiling lights
Switch, socket 1 10A switch, 3 10A five-hole sockets, 1 16A three-hole air conditioning socket

Advantage:

1. Fast installation speed.

2. More economical.

3. Less geographical restrictions.

4. Long service life.

5. Safe and stable.

6. Good sealing performance.

7. The activity room is green and environmentally friendly.

8. Easy accessibility, superior performance9. More combinations.

large Prefab Shipping Container / Office Prefabricated Storage Container Homeslarge Prefab Shipping Container / Office Prefabricated Storage Container Homeslarge Prefab Shipping Container / Office Prefabricated Storage Container Homes
