Specifications
Brand Name :
CIVL
Certification :
ISO 9001-2000, CCC
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
200000 units/month
Delivery Time :
Within 25 days
Packaging Details :
suitable package by container
Window :
Aluminum alloy
Door :
Steel Door,Security Door
Material :
Sandwich Panel
Type :
Customizable,prefabricated
Floor :
floor tile/composite board
Application :
Workshop
Wall :
sandwich pannel
Product name :
Container house
Description

Modern Prefab Guest House Prefabricated Container Homes Storage Container Homes

The dimension and material of container house:

Container house Length 5950mm(inner:5790mm)
Width 3000mm(inner:2830mm)
Height 2780mm(inner:2500mm)
Floor no. 1-3

Structure Steel column Galvanized bending steel,160mm*160mm*2450mm t=2.0mm
Roof girder Galvanized square tube120x60x1.5/30x30x1.5
Roof secondary beam Galvanized rectangular tube,40mm*60mm t=1.5mm
Ground girder Galvanized extruded steel,5955mm*3000mm*148mm Galvanized square tube120x60x1.2/30x30x1.2
Ground secondary beam Galvanized rectangular tube,40mm*60mm t=1.5mm
Ground secondary beam Galvanized rectangular tube,80mm*80mm t=1.5mm
Surface treatment Environmental protection water-based paint, primer + topcoat≥80μm；Color no.:RAL9018
Roofing Roofing V970 color steel single tile t=0.34mm
Insulation cotton Glass wool, bulk density ≥14kg / m³ t=50mm
Suspended ceiling Aluminum-plated zinc color steel plate, color white gray t=0.4mm
floor Substrate + moisture-proof film Fire retardant fiberboard, density ≥1.2g / m³, flame retardant class B t = 15mm
Wall Color coated board material Double-sided aluminum-plated zinc color coated board, PE coating t=0.3mm
Insulation Flame retardant glass wool, bulk density ≥40kg / m³, flame retardant A grade, t = 50mm
Door Specification WxH=950mm*1960mm
Window Specification WxH=960mm*1000mm with Screen
Frame material Upvc window frame sliding series
Glass Normal Glass
Electricity Voltage 220V～250V,50Hz,3-stage,32A
Line Three-core cable = 4㎡, socket cable = 2.5㎡, lighting switch cable = 1.5㎡
breaker High breaking small circuit breaker with leakage switch
Light Two sets of single tube LED ceiling lights
Switch, socket 1 10A switch, 3 10A five-hole sockets, 1 16A three-hole air conditioning socket

Custom Made Modern Prefab Guest House , Prefabricated Storage Container Homes

Custom Made Modern Prefab Guest House , Prefabricated Storage Container HomesCustom Made Modern Prefab Guest House , Prefabricated Storage Container Homes

Advantage:

1. Fast installation speed.

2. More economical.

3. Less geographical restrictions.

4. Long service life.

5. Safe and stable.

6. Good sealing performance.

Prefab shipping container,Cargo container,Building prefab,Shipping container home, Modular flat pack container office,Tiny house modular homes, Mobile homes,Trailers, Container house,Container home, movable house, movable toilet,mobile toilet,mobile bathroom,board room,board house,box room,box home,tow box,tow house,tow home,Modern-box-home,Box type house,Contemporary family box house,Container house luxury,Container coffee shop,Container restaurant,Container s, Container hotel,Luxury modern container design s, prefabricated modular houses,

cheap mobile container homes prefab luxury container house apartment,

Luxury 40ft Home Shipping Container House Villa Container , 40 ft HC

Prefabricated portable toilet container s,

Prefabricated shopping mall, prefabricated container house price prefab modern modular container houses/homes/hotels,

Extended Folded Prefab Container Homes,

folding prefabricated house

Mobile hospital, Movable Hospital
