Specifications
Brand Name :
CIVL
Certification :
ISO 9001-2000, CCC
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
200000 units/month
Delivery Time :
Within 25 days
Packaging Details :
suitable package by container
Use :
House
Color :
Optional
Size :
According to Customer Requirement
Window :
Aluminum alloy
Door :
Steel Door,Security Door
Material :
Sandwich Panel
Type :
Customizable,prefabricated
Floor :
floor tile/composite board
Application :
Workshop
Wall :
sandwich pannel(50mm/75mm EPS)
Product name :
Container house
Description

Prefabricated Container Toilet Economical Prefab Homes Prefab Modern Modular Container Houses/Homes/hotels

Manufacturing Technology

*** Material : full-color steel sandwich panel/75-100mm glass fiber sandwich panel,

***Q235 strip steel frame structure

***galvanized and anti-rust, anti-corrosion,

***18mm thickness cement particle board .

The dimension and material of container house:

Container house Length 5950mm(inner:5790mm)
Width 3000mm(inner:2830mm)
Height 2780mm(inner:2500mm)
Floor no. 1-3

Structure Steel column Galvanized bending steel,160mm*160mm*2450mm t=2.0mm
Roof girder Galvanized square tube120x60x1.5/30x30x1.5
Roof secondary beam Galvanized rectangular tube,40mm*60mm t=1.5mm
Ground girder Galvanized extruded steel,5955mm*3000mm*148mm Galvanized square tube120x60x1.2/30x30x1.2
Ground secondary beam Galvanized rectangular tube,40mm*60mm t=1.5mm
Ground secondary beam Galvanized rectangular tube,80mm*80mm t=1.5mm
Surface treatment Environmental protection water-based paint, primer + topcoat≥80μm；Color no.:RAL9018
Roofing Roofing V970 color steel single tile t=0.34mm
Insulation cotton Glass wool, bulk density ≥14kg / m³ t=50mm
Suspended ceiling Aluminum-plated zinc color steel plate, color white gray t=0.4mm
floor Substrate + moisture-proof film Fire retardant fiberboard, density ≥1.2g / m³, flame retardant class B t = 15mm
Wall Color coated board material Double-sided aluminum-plated zinc color coated board, PE coating t=0.3mm
Insulation Flame retardant glass wool, bulk density ≥40kg / m³, flame retardant A grade, t = 50mm
Door Specification WxH=950mm*1960mm
Window Specification WxH=960mm*1000mm with Screen
Frame material Upvc window frame sliding series
Glass Normal Glass
Electricity Voltage 220V～250V,50Hz,3-stage,32A
Line Three-core cable = 4㎡, socket cable = 2.5㎡, lighting switch cable = 1.5㎡
breaker High breaking small circuit breaker with leakage switch
Light Two sets of single tube LED ceiling lights
Switch, socket 1 10A switch, 3 10A five-hole sockets, 1 16A three-hole air conditioning socket

Advantage:

1. Fast installation speed.

2. More economical.

3. Less geographical restrictions.

4. Long service life.

5. Safe and stable.

6. Good sealing performance.

7. The activity room is green and environmentally friendly.

8. Easy accessibility, superior performance9. More combinations.

FAQ:

Q1: Delivery time?

A1: Within 15-30 days,According to your quantity and color.

Q2: Production ability?

A2: 200,000units/month.

Q3: How to install?

A3: With install instruction and video,

QTY≧1000m2 technicians will be sent off if it is requested(visa fee,air tickets,accommodation, beared by buyers).

Q5: Package?

A5: By 20ft/40ft container.By bulk vessel if large qty.

Q6: Lifetime:

A6: 10years

Prefabricated Container Toilet Economical Prefab Homes Prefab Modern Modular Container HousesPrefabricated Container Toilet Economical Prefab Homes Prefab Modern Modular Container Houses
