Hss Twist Drill Bits DIN 338
Hss Twist Drill Bits DIN 338
Specifications
Place of Origin :
China
Brand Name :
WXM
MOQ :
100pcs
Packaging Details :
paper bag packing or plastic tube packing or absorbing clip packing
Delivery Time :
30days
Payment Terms :
T/T 50%at first,50%before the goods delivered
Supply Ability :
10000000pcs
Drill Type :
twist drill
Description

HSS Twist Drill Bits, DIN338, RolledM
Manufacturing Process:Roll Forged;
Material: HSS;
Sizes:0.2mm-20mm;
Surface Finishing:Black, Gray & White, Gray;
Point Angle:118°

 Hss Twist Drill Bits DIN 338 10HO1111

---

 10HO1115
Hss Twist Drill Bits DIN 338 10HO1118

HSS Drill Bits,DIN338, Rolled & Polished.
Manufacturing Process:Rolled & Polished;
Material: HSS;
Sizes:0.2mm-20mm;
Surface Finishing:White,TIN coated;
Point Angle:118°or 135"(Split point are available from 3mm)

 Hss Twist Drill Bits DIN 338 10HO1122
Hss Twist Drill Bits DIN 338 10HO1123

HSS Twist Drill Bits, DIN338, Fully Ground
Manufacturing Process:fully ground;
Material: HSS;
Sizes:0.2mm-20mm;
Surface Finishing:Black, Black & White, Coffee, etc.;
Point Angle:118°or 135° (Split Point are available from 3mm)

 Hss Twist Drill Bits DIN 338 10HO1132
Hss Twist Drill Bits DIN 338 10HO1131
Hss Twist Drill Bits DIN 338 10HO1133
Hss Twist Drill Bits DIN 338 10HO1137
Hss Twist Drill Bits DIN 338 10HO1136
Hss Twist Drill Bits DIN 338 10HO1139

HSS-E Drill Bits,DIN338,Fully Ground
Manufacturing Process:Fully Ground;
Material:HSS Co;
Sizes:0.2mm-20mm;
Surface Finishing:Coffee Color;
Point Angle:135° (Split Point are available from 3mm)

 Hss Twist Drill Bits DIN 338 10HO1134
Hss Twist Drill Bits DIN 338

D(mm) L2(mm) L1(mm) D(mm) L2 (mm) L1(mm) D(mm) L2 (mm) L1(mm) D(mm) L2 (mm) L1(mm)
0.2 2.5 19 1.95 24 49 6 57 93 11.2 94 142
0.22 2.5 19 2 24 49 6.1 63 101 11.3 94 142
0.25 3 19 2.05 24 49 6.2 63 101 11.4 94 142
0.28 3 19 2.1 24 49 6.3 63 101 11.5 94 142
0.3 3 19 2.15 27 53 6.4 63 101 11.6 94 142
0.32 4 19 2.2 27 53 6.5 63 101 11.7 94 142
0.35 4 19 2.25 27 53 6.6 63 101 11.8 94 142
0.38 4 19 2.3 27 53 6.7 63 101 11.9 101 151
0.4 5 20 2.35 27 53 6.8 69 109 12 101 151
0.42 5 20 2.4 30 57 6.9 69 109 12.1 101 151
0.45 5 20 2.45 30 57 7 69 109 12.2 101 151
0.48 5 20 2.5 30 57 7.1 69 109 12.3 101 151
0.5 6 22 2.55 30 57 7.2 69 109 12.4 101 151
0.52 6 22 2.6 30 57 7.3 69 109 12.5 101 151
0.55 7 24 2.65 30 57 7.4 69 109 12.6 101 151
0.58 7 24 2.7 33 61 7.5 69 109 12.7 101 151
0.6 7 24 2.75 33 61 7.6 75 117 12.85 101 151
0.62 8 26 2.8 33 61 7.7 75 117 12.9 101 151
0.65 8 26 2.85 33 61 7.8 75 117 13 101 151
0.68 9 28 2.9 33 61 7.9 75 117 13.1 101 151
0.7 9 28 2.95 33 61 8 75 117 13.2 101 151
0.72 9 28 3 33 61 8.1 75 117 13.3 108 160
0.75 9 28 3.1 36 65 8.2 75 117 13.4 108 160
0.78 10 30 3.2 36 65 8.3 75 117 13.5 108 160
0.8 10 30 3.3 36 65 8.4 75 117 13.6 108 160
0.82 10 30 3.4 39 70 8.5 75 117 13.7 108 160
0.85 10 30 3.5 39 70 8.6 81 125 13.8 108 160
0.88 11 32 3.6 39 70 8.7 81 125 13.9 108 160
0.9 11 32 3.7 39 70 880 81 125 14 108 160
0.92 11 32 3.8 43 75 8.9 81 125 14.25 114 169
0.95 11 32 3.9 43 75 9 81 125 14.5 114 169
0.98 12 34 4 43 75 9.1 81 125 14.75 114 169
1 12 34 4.1 43 75 9.2 81 125 15 114 169
1.05 12 34 4.2 43 75 9.3 81 125 15.25 120 178
1.1 14 36 4.3 47 80 9.4 81 125 15.5 120 178
1.15 14 36 4.4 47 80 9.5 81 125 15.75 120 178
1.2 16 38 4.5 47 80 9.6 87 133 16 120 178
1.25 16 38 4.6 47 80 9.7 87 133 16.25 125 184
1.3 16 38 4.7 47 80 9.8 87 133 16.5 125 184
1.35 18 40 4.8 52 86 9.9 87 133 16.75 125 184
1.4 18 40 4.9 52
